Technical Specifications
| Item | Specification |
|---|---|
| Model | 330101-00-24-01-02-05 |
| Type | 8 mm Eddy-Current Proximity Probe |
| Thread Size | 3/8-24 UNF |
| Unthreaded Length | 0 in (00 option) |
| Case (Body) Length | 2.4 in (24 option) |
| Cable Length | 0.1 m (01 option) |
| Connector Type | Miniature coaxial ClickLoc (02 option) |
| Approvals | CSA, ATEX, IECEx (05 option) |
| Measurement Principle | Non-contact eddy-current displacement measurement |
| Linear Measurement Range | Approx. 0.25 mm to 2.3 mm |
| Sensitivity | 7.87 V/mm (≈200 mV/mil) nominal |
| Frequency Response | Suitable for high-speed machinery monitoring |
| Operating Temperature | –52 °C to +177 °C (standard) |
| Tip Material | PPS (polyphenylene sulfide) |
| Housing Material | Stainless steel |
| Recommended Gap | –9 Vdc (≈1.27 mm) |
| Wiring Requirements | 3-conductor shielded triad cable, 16–24 AWG |
| Maximum Field Wiring Length | Up to 305 m (1,000 ft) |
| Pressure Seal | Viton O-ring |
| Dimensions | Probe tip diameter 8 mm; body length 2.4 in; cable length 0.1 m |
| Weight | Approx. 0.31 kg |
FAQ
FAQ
Q1: What is the main function of the 330101-00-24-01-02-05 probe?
A1: It is used to measure shaft vibration, radial displacement, and position in rotating machinery using non-contact eddy-current technology.
Q2: What does “24-01-02-05” indicate in the model number?
A2: “24” specifies body length (2.4 in), “01” indicates cable length (0.1 m), “02” is the connector type (ClickLoc), and “05” denotes CSA, ATEX, and IECEx approvals.
Q3: Can this probe be used with 3300 XL proximitor sensors?
A3: Yes, it is fully compatible with 3300 XL Proximitor systems for precise monitoring.
Q4: Is this probe suitable for harsh industrial environments?
A4: Yes, its stainless-steel housing, PPS tip, and certified design allow operation in oil, vibration, and high-temperature conditions.
Q5: What is the linear measurement range?
A5: Approximately 0.25 mm to 2.3 mm.
Q6: What supply voltage does this probe require?
A6: A negative DC supply between –17.5 Vdc and –26 Vdc is required.
Q7: Can it monitor high-speed machinery?
A7: Yes, its frequency response supports high-speed rotating equipment.
Q8: What are the physical dimensions and weight of the probe?
A8: Probe tip diameter 8 mm, body length 2.4 inches, cable length 0.1 m, weight approximately 0.31 kg.
