Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | 330171-00-14-10-02-05 |
| Manufacturer | Bently Nevada |
| Product Series | 3300 XL Proximity Transducer System |
| Product Type | Proximitor® Sensor |
| Measurement Principle | Eddy-current displacement measurement |
| System Compatibility | 3300 XL 8 mm proximity probe system |
| Output Signal | 4–20 mA proportional to vibration or displacement |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Linear Measurement Range | 2 mm (80 mils) |
| Supply Voltage | −17.5 VDC to −26 VDC |
| Current Consumption | Approximately 12 mA |
| Frequency Response | 0 – 10 kHz |
| Connector Type | Coaxial connectors for probe and extension cable |
| Mounting Type | DIN rail or panel mounting |
| Operating Temperature | −35°C to +85°C |
| Dimensions (Module Housing) | Approx. 122 mm × 120 mm × 50 mm |
| Weight | Approximately 0.4 kg |
| Typical Applications | Shaft vibration monitoring, shaft position measurement, and rotating machinery protection |
| Compliance Standards | API 670 compatible machinery protection systems |
FAQ
FAQ
Q1. What is the function of the 330171-00-14-10-02-05 Proximitor sensor?
It converts signals from the proximity probe into electrical outputs that represent shaft vibration or displacement.
Q2. Which probe system is compatible with this sensor?
It is designed to operate with the Bently Nevada 3300 XL 8 mm proximity probe system.
Q3. What type of output signal does this sensor provide?
It provides a proportional signal that can be configured for vibration or displacement monitoring, typically 4–20 mA.
Q4. What is the measurement sensitivity of this sensor?
The standard sensitivity is 200 mV per mil (7.87 V/mm).
Q5. What voltage is required to power the sensor?
The device operates with a supply voltage between −17.5 VDC and −26 VDC.
Q6. What temperature range can the sensor operate in?
The operating temperature range is approximately −35°C to +85°C.
Q7. Where is this sensor commonly used?
It is widely used in turbines, compressors, pumps, and other critical rotating equipment.
Q8. Why are Proximitor sensors important in vibration monitoring systems?
They condition and convert probe signals into stable outputs that can be interpreted by monitoring and protection systems.
