Technical Specifications
| Item | Specification |
|---|---|
| Model | Bently Nevada 330171-00-20-90-02-05 |
| Type | 3300 Series 5 mm Eddy-Current Proximity Probe |
| Measurement Principle | Eddy current technology |
| Probe Tip Diameter | 5 mm |
| Thread Type | 1/4-28 UNF |
| Probe Body Length | 20 mm |
| Unthreaded Length | 0 mm |
| Cable Length | 9.0 m (29.5 ft) |
| Connector Type | Miniature coaxial ClickLoc connector |
| Sensitivity | Typical for 5 mm proximity probe systems |
| Frequency Response | Suitable for vibration and position monitoring of rotating machinery |
| Housing Material | Stainless steel |
| Mounting Method | Threaded installation |
| Operating Temperature Range | –35 °C to +177 °C |
| Application Environment | Industrial, oil-resistant, vibration-resistant |
| Matching Components | 3300 XL Proximitor Sensor and compatible extension cables |
| Applications | Shaft vibration, axial position, and displacement monitoring |
| Dimensions | Probe tip diameter 5 mm; probe body length 20 mm; cable length 9.0 m |
| Weight | Approximately 0.45 kg |
| Approvals | Multiple agency / hazardous area approvals (05 option) |
FAQ
FAQ
Q1: What is the primary application of the 330171-00-20-90-02-05 proximity probe?
It is used to measure shaft vibration, axial position, and displacement in rotating machinery.
Q2: What does the “330171” series indicate?
It identifies a 3300 Series 5 mm proximity probe designed for industrial eddy-current measurements.
Q3: What does the “20-90-02-05” configuration represent?
It specifies a 20 mm probe body length, a 9.0 m integral cable, a ClickLoc connector, and multiple agency or hazardous area approvals.
Q4: Which systems is this probe compatible with?
It is designed to operate with Bently Nevada 3300 XL Proximitor Sensors and related monitoring modules.
Q5: Can this probe be used in harsh industrial environments?
Yes, the stainless-steel construction and robust design make it suitable for oil-contaminated, high-vibration, and regulated industrial environments.
Q6: What type of output does this proximity probe provide?
It provides an analog voltage output proportional to the measured displacement or vibration.
Q7: What is the operating temperature range of this probe?
The probe operates reliably from –35 °C to +177 °C.
Q8: What are the physical dimensions and weight of the probe?
The probe has a 5 mm tip diameter, a 20 mm body length, a 9.0 m cable, and a total weight of approximately 0.45 kg.
