Technical Specifications
| Item | Specification |
|---|---|
| Product Type | Proximitor Sensor |
| Model Number | 330180-X1-05 |
| Part Number | 145193-01 |
| Series | 3300 XL 8 mm |
| Input Supply Voltage | -24 VDC (from monitoring system) |
| Output Signal | Voltage proportional to gap (200 mV/mil, 7.87 mV/µm) |
| Measurement Range | -2.0 mm to +2.0 mm (typical) |
| Sensitivity | 200 mV/mil (7.87 mV/µm) |
| Frequency Response | 0 to 10 kHz (±3 dB) |
| Operating Temperature | -35 °C to +177 °C |
| Storage Temperature | -40 °C to +100 °C |
| Shock Limit | 500 g, 1 ms half-sine |
| Vibration Limit | 20 g, 10–2000 Hz |
| Dimensions | 81.3 x 35.1 x 63.5 mm |
| Weight | 0.246 kg |
| Housing Material | Shielded aluminum with EMI protection |
| Applications | Shaft displacement, vibration, and clearance monitoring |
FAQ
FAQ
Q1: What is the main purpose of the 330180-X1-05 145193-01 Proximitor Sensor?
It monitors shaft displacement, vibration, and clearance in rotating machinery.
Q2: Which probes is it compatible with?
It must be used with 3300 XL 8 mm proximity probes and extension cables.
Q3: What is the sensitivity?
The typical sensitivity is 200 mV/mil (7.87 mV/µm).
Q4: What is the measurement range?
The measurement range is -2.0 mm to +2.0 mm.
Q5: What is the operating temperature range?
-35 °C to +177 °C.
Q6: What are the power requirements?
Powered by -24 VDC supplied from the monitoring system.
Q7: What are the dimensions and weight?
Dimensions: 81.3 x 35.1 x 63.5 mm; Weight: 0.246 kg.
Q8: Which machines commonly use this sensor?
It is mainly used in turbines, compressors, motors, and other rotating machinery for condition monitoring.
