Technical Specifications
| Category | Specification |
|---|---|
| Output Scale Factor | 0.787 V/mm (20 mV/mil) nominal |
| Linear Range | 12.7 mm (500 mils), from 0.63 mm to 13.33 mm |
| Power Supply | -17.5 Vdc to -26 Vdc (without barriers) |
| -23 Vdc to -26 Vdc (with barriers) | |
| Power Consumption | 12 mA max |
| Frequency Response | 0–2.7 kHz typical, with up to 305 m of field wiring |
| Temperature Ranges | Probe: -35°C to +200°C (short-term up to +250°C) |
| Extension Cable: -35°C to +200°C | |
| Proximitor Sensor: -51°C to +100°C (storage to +105°C) | |
| Materials | Probe: AISI 304 SST; Proximitor: A380 Aluminum |
| Total Length | 5.0 meters including extension cable |
| Weight | Approx. 0.255 kg |
| Cable Capacitance | 69.9 pF/m typical |
| Recommended Target Size | ≥ 61 mm diameter (AISI 4140 steel) |
| Mechanical Tensile Strength | Max 330 N from probe case to lead |
| Mounting Options | Panel or DIN rail mounting |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the scale factor of the 330850-51-05 sensor?
A1: The nominal output is 0.787 V/mm (20 mV/mil).
Q2: What type of application is this sensor designed for?
A2: It is used for differential expansion (DE) measurement in steam turbines.
Q3: What is the maximum operating temperature of the probe?
A3: It operates continuously up to 200°C and tolerates short-term peaks of 250°C.
Q4: What is the total system length including extension cable?
A4: The system length is 5.0 meters.
Q5: What is the typical frequency response of the system?
A5: 0 to 2.7 kHz with typical +0, -3 dB response.
Q6: Is the sensor compatible with both panel and DIN mountings?
A6: Yes, it supports both DIN-rail and panel mount installations.
Q7: Will using a target other than AISI 4140 affect measurement accuracy?
A7: Yes, calibration and accuracy are specified for AISI 4140 targets. Other materials require recalibration.
Q8: Does the sensor comply with regulatory certifications?
A8: Yes, it complies with CE, RoHS, EMC, CSA/NRTL, and other hazardous area standards.
