Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Bently Nevada 330878-51-05 |
| Type | 3300 XL 50 mm Proximitor Sensor |
| Dimensions | Total Length : 5.0 meters |
| Weight | 0.22 kg |
| Compatible Probes | 3300 XL 50 mm Probes |
| Cable Length | 5 m (suffix “-05” indicates 5-meter cable) |
| Power Supply | Powered by monitoring system |
| Output Voltage | -14 V to -22 V (corresponding to full-scale displacement) |
| Measurement Range | 2 mm to 50 mm (depending on probe and installation) |
| Linearity | ±1% of full scale |
| Resolution | ≤ 0.01 mm |
| Frequency Response | DC to 10 kHz (-3 dB) |
| Operating Temperature | -35°C to +100°C |
| Storage Temperature | -40°C to +125°C |
| Humidity | 95% non-condensing |
| EMC | Complies with IEC/EN standards |
| Insulation Resistance | ≥ 100 MΩ |
| Mounting | Panel or Rail mounting |
| Housing Material | Aluminum alloy with protective coating |
| Protection Rating | IP65 |
FAQ
FAQ
Q1: Which probes is the 330878-51-05 Proximitor designed for?
It is specifically designed for Bently Nevada 3300 XL 50 mm probes.
Q2: What does the suffix “-05” mean in the model?
“-05” indicates that the unit comes with a 5-meter cable length.
Q3: What is the operating temperature range?
It can operate within -35°C to +100°C.
Q4: Does this sensor require an external power supply?
No, it is powered directly by the monitoring system.
Q5: What is the output voltage range?
The output voltage ranges from -14 V to -22 V corresponding to full-scale probe displacement.
Q6: Is field replacement supported?
Yes, modular replacement is supported, but only when the system is powered off.
Q7: What are the dimensions and weight?
Dimensions: Total Length : 5.0 meters; Weight: 0.22 kg.
Q8: What are the typical applications?
It is used for shaft displacement and vibration monitoring in turbines, compressors, pumps, and other rotating machinery.
