Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Non-contacting proximity transducer system |
| Linear Range | 27.9 mm (1.1 in), from 1.3 to 29.2 mm (50 to 1150 mils) |
| Scale Factor (ASF) | 394 mV/mm (10 mV/mil) nominal |
| Power Supply | -17.5 Vdc to -26 Vdc, 12 mA max |
| Output Resistance | 50 Ω |
| Extension Cable Capacitance | 69.9 pF/m (21.3 pF/ft) typical |
| Field Wiring Recommendation | 0.2 to 1.5 mm² (16 to 24 AWG), shielded triad |
| Operating Temperature – Probe | -35°C to +200°C (-31°F to +392°F) |
| Short-Term High Temp – Probe | Up to +250°C (482°F) for <24 hours |
| Operating Temp – Proximitor | -51°C to +100°C (-60°F to +212°F) |
| Material – Probe Tip | Polyphenylene Sulfide (PPS) |
| Material – Probe Case | AISI 304 Stainless Steel |
| Material – Proximitor Sensor | A380 Aluminum |
| Sensor Mounting | Panel or DIN rail |
| Min Target Size | 102 mm (4 in) flat diameter |
| Compliance | CE, RoHS, FCC, ATEX/IECEx compliant |
| System Length (probe + cable) | 9.0 meters |
| Total Weight | 0.22 kg |
| Minimum Bend Radius | 25.4 mm (1 in) |
FAQ
FAQ
Q1: What is the linear measurement range of the 330878-90-00 sensor?
A1: The linear range is 27.9 mm (1.1 inches), beginning at 1.3 mm from the target.
Q2: Is this sensor suitable for high-temperature environments?
A2: Yes, the probe can operate continuously up to 200°C and withstand 250°C for short durations.
Q3: Can this sensor be used in hazardous areas?
A3: Yes, it has multiple hazardous area approvals including ATEX, IECEx, and cNRTLus classifications.
Q4: What is the output scale factor?
A4: The sensor provides an average scale factor of 394 mV/mm (10 mV/mil).
Q5: What is the required power supply range?
A5: It requires a -17.5 Vdc to -26 Vdc power supply.
Q6: Does it require a specific target material?
A6: It is factory calibrated for AISI 4140 steel; other materials require recalibration.
Q7: What is the recommended field wiring for this sensor?
A7: Use 3-conductor shielded triad cables sized between 0.2 to 1.5 mm² (16–24 AWG).
Q8: Can this sensor be mounted on both DIN rails and panels?
A8: Yes, it supports both DIN rail and traditional panel mounting options.
