Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 330881-28-04-090-03-02 |
| Product Name | Bently Nevada Velomitor Piezo-Velocity Sensor |
| Dimensions | Body length: 64 mm ; Body diameter: 28 mm ; Cable length: 9.0 metres |
| Output Type | Velocity output (piezoelectric) |
| Sensitivity | 3.94 mV/mm/s (100 mV/in/s) typical |
| Frequency Range | 10–1,000 Hz typical |
| Mounting Type | Stud-mounted |
| Cable Configuration | 090 = 9.0-metre integral cable |
| Cable Shield Style | 04 = Shielded cable type |
| Connector/Termination Code | 03 = Standard termination style |
| Region/Agency Code | 02 = Standard certified version |
| Operating Temperature Range | –40 °C to +100 °C |
| Weight | ≈ 0.38 kg (including cable) |
| Housing Material | Stainless steel |
| Application | Low-frequency vibration monitoring for rotating machinery |
FAQ
FAQ
Q1: What is the purpose of the 330881-28-04-090-03-02 sensor?
It measures low-frequency vibration on rotating machinery using a piezo-velocity sensing element.
Q2: What does “28” denote in the part number?
It indicates the 28-mm body diameter Velomitor sensor style.
Q3: What does the “04” specify?
It identifies the shielded cable type used in this sensor configuration.
Q4: What does “090” indicate in the model number?
It represents an integral cable length of 9.0 metres.
Q5: What does the “03” termination code mean?
It designates a standard cable termination used for general industrial installations.
Q6: What does “02” at the end of the part number signify?
It indicates a standard global certification version.
Q7: Can this sensor be used in harsh environments?
Yes, the stainless-steel body and –40 °C to +100 °C rating make it suitable for demanding industrial environments.
Q8: What are the physical dimensions and weight of the sensor?
Body length: 64 mm ; Body diameter: 28 mm ; Cable length: 9.0 metres ; Weight: ≈ 0.38 kg.
