Technical Specifications
| Item | Specification |
|---|---|
| Model | Bently Nevada 330901-00-78-10-02-00 |
| Type | 3300 XL Proximitor Sensor |
| Product Category | Machinery Condition Monitoring Electronics |
| Product Family | 3300 XL Series |
| Function | Conditions and converts proximity probe signals into a proportional voltage output |
| Measurement Principle | Eddy-current signal conditioning and conversion |
| Input Compatibility | 3300 XL proximity probes and extension cables |
| Output Signal | Analog voltage proportional to displacement |
| Power Supply Requirement | 18 V to 30 V DC |
| Frequency Response | DC to 10 kHz (typical) |
| System Calibration | Factory calibrated with matched probe and cable |
| Housing Material | Aluminum alloy |
| Mounting Method | DIN-rail or panel mounting |
| Operating Temperature Range | –35 °C to +65 °C |
| Application Environment | Industrial rotating machinery monitoring |
| Dimensions | Approx. 114 mm × 114 mm × 51 mm |
| Weight | Approx. 0.45 kg |
FAQ
FAQ
Q1: What is the function of the 330901-00-78-10-02-00 Proximitor Sensor?
It conditions the raw signal from a 3300 XL proximity probe and outputs a stable voltage for monitoring systems.
Q2: Is this product itself a proximity probe?
No, it is a Proximitor Sensor that works with proximity probes and extension cables to provide a conditioned output.
Q3: Which probes are compatible with this Proximitor?
It is designed to work with Bently Nevada 3300 XL proximity probes.
Q4: What does the “78” in the model number signify?
It identifies a specific internal configuration or version of the Proximitor within the 3300 XL family.
Q5: What output signal type does this Proximitor provide?
It provides an analog voltage output proportional to shaft displacement as measured by the probe.
Q6: Does this Proximitor require field calibration?
No, it is factory calibrated when used with the appropriate matched components.
Q7: What are the physical dimensions and weight of this unit?
The sensor’s housing measures approximately 114 mm × 114 mm × 51 mm and weighs about 0.45 kg.
Q8: Where is this Proximitor typically installed?
It is usually mounted on a DIN rail or panel within industrial monitoring and control cabinets.
