Technical Specifications
| Item | Specification |
|---|---|
| Model | Bently Nevada 330901-20-63-05-02-CN |
| Type | 3300 XL Proximitor Sensor |
| Product Category | Machinery Condition Monitoring Electronics |
| Product Family | 3300 XL Series |
| Function | Conditions proximity probe signals and provides a proportional voltage output |
| Measurement Principle | Eddy-current signal conditioning |
| Input Compatibility | Works with 3300 XL proximity probes and extension cables |
| Output Signal | Analog voltage proportional to shaft displacement |
| Power Supply Requirement | 18 V to 30 V DC |
| Frequency Response | DC to 10 kHz (typical) |
| Calibration | Factory calibrated with matched 3300 XL components |
| Housing Material | Aluminum alloy |
| Mounting Method | DIN rail or panel mounting |
| Operating Temperature Range | –35 °C to +65 °C |
| Regional Option | CN version (for China market) |
| Application Environment | Industrial rotating machinery monitoring |
| Dimensions | Approx. 114 mm × 114 mm × 51 mm |
| Weight | Approx. 0.45 kg |
FAQ
FAQ
Q1: What is the function of the 330901-20-63-05-02-CN Proximitor Sensor?
It converts and conditions the signal from a 3300 XL proximity probe into a stable voltage output for monitoring systems.
Q2: Is this product a sensor or a probe?
It is a Proximitor Sensor module that works together with proximity probes and extension cables; it is not a probe itself.
Q3: What does the “CN” suffix indicate?
It denotes a configuration intended for the China market.
Q4: Which probes is this Proximitor compatible with?
It is designed for use with Bently Nevada 3300 XL proximity probes and matching extension cables.
Q5: Do I need to calibrate this unit on site?
No, it is typically factory calibrated when used with matched 3300 XL components.
Q6: Can this Proximitor support both vibration and position measurement?
Yes, it supports dynamic vibration and static shaft position monitoring when paired with the correct probes.
Q7: What are the physical dimensions and weight of this unit?
The housing measures approximately 114 mm × 114 mm × 51 mm and weighs about 0.45 kg.
Q8: Where is this Proximitor typically installed?
It is commonly mounted on a DIN rail or panel inside industrial control or monitoring cabinets.
