Technical Specifications
| Item | Specification |
|---|---|
| Model | 330902-04-40-10-02-CN |
| Series | Bently Nevada 3300 NSv (Narrow Side View) |
| Type | Eddy-Current Proximity Probe |
| Probe Diameter | 5 mm |
| Probe Length | 40 mm |
| Measurement Range | 2 mm (80 mils) |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Linear Range | 0.25 ~ 2.00 mm |
| Frequency Range | DC ~ 10 kHz |
| Probe Material | Stainless steel housing |
| Cable Length | 10 m (with detachable coaxial connector) |
| Connector Type | Miniature coaxial connector |
| Compatible Sensor | 3300 NSv Proximitor Sensor |
| Operating Temperature | -35 ~ +177 ℃ |
| Storage Temperature | -50 ~ +200 ℃ |
| Insulation Resistance | ≥ 10 MΩ @ 500 V DC |
| Dimensions | Total Length : 1.0 meter |
| Weight | 0.15 kg |
FAQ
FAQ
Q1: Which series does this probe belong to?
It belongs to the Bently Nevada 3300 NSv series, designed for precise displacement measurement in confined spaces.
Q2: What is the measurement range of this probe?
It provides a measurement range of 2 mm (80 mils).
Q3: What is the sensitivity of the probe?
The sensitivity is 7.87 V/mm (200 mV/mil).
Q4: What is the cable length?
It includes a 10-meter cable with a detachable coaxial connector for easy installation and maintenance.
Q5: Which sensors is it compatible with?
Fully compatible with the Bently Nevada 3300 NSv Proximitor Sensor.
Q6: What is the operating temperature range?
The operating temperature range is -35°C to +177°C.
Q7: What material is used for the probe housing?
Constructed from high-grade stainless steel for superior corrosion and wear resistance.
Q8: What are the typical application areas?
Commonly used for shaft vibration and displacement monitoring in gas turbines, compressors, generators, and gearboxes.
