Technical Specifications
| Item | Specification |
|---|---|
| Model | 330902-04-48-10-02-05 |
| Series | Bently Nevada 3300 NSv (Narrow Side View) |
| Type | Eddy-Current Proximity Probe |
| Probe Diameter | 5 mm |
| Probe Length | 48 mm |
| Measurement Range | 2 mm (80 mils) |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Linear Range | 0.25 ~ 2.00 mm |
| Frequency Range | DC ~ 10 kHz |
| Probe Material | Stainless steel housing |
| Cable Length | 10 m (with detachable coaxial connector) |
| Connector Type | Miniature coaxial connector |
| Compatible Sensor | 3300 NSv Proximitor Sensor |
| Operating Temperature | -35 ~ +177 ℃ |
| Storage Temperature | -50 ~ +200 ℃ |
| Insulation Resistance | ≥ 10 MΩ @ 500 V DC |
| Dimensions | Total Length : 1.0 meter |
| Weight | 0.15 kg |
FAQ
FAQ
Q1: Which series does this probe belong to?
It belongs to the Bently Nevada 3300 NSv series, designed for displacement monitoring in confined installations.
Q2: What is the measurement range of this probe?
It provides a measurement range of 2 mm (80 mils).
Q3: What is the probe sensitivity?
The sensitivity is 7.87 V/mm (200 mV/mil).
Q4: What is the cable length of the probe?
It comes with a 10-meter cable featuring a detachable coaxial connector for easy setup and replacement.
Q5: Which sensors is this probe compatible with?
It is fully compatible with Bently Nevada 3300 NSv Proximitor Sensors.
Q6: What is the operating temperature range?
The operating temperature range is -35°C to +177°C, suitable for demanding industrial environments.
Q7: What material is the probe housing made from?
It is made from high-quality stainless steel, offering excellent corrosion resistance and durability.
Q8: What are the typical applications for this probe?
Commonly used in gas turbines, compressors, generators, and gearboxes for shaft vibration and displacement monitoring.
