Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Bently Nevada 330903-00-05-50-02-00 |
| Product ID | 330903-00-05-50-02-00 |
| Manufacturer | Bently Nevada |
| Product Type | 3300 NSv Proximitor® Sensor |
| Series | 3300 NSv Proximity Transducer System |
| Function | Signal conditioning and conversion of proximity probe signals into proportional vibration and position outputs |
| Probe Compatibility | Bently Nevada 3300 NSv Proximity Probe |
| System Length | 5.0 m System (Option 50) |
| Mounting Option | Panel Mount (Option 05) |
| Connector Type | Miniature ClickLoc™ Connectors |
| Agency Approval | None Required (Option 00) |
| Output Sensitivity | 200 mV/mil (7.87 V/mm) |
| Measurement Technology | Eddy Current Proximity Measurement |
| Frequency Response | 0.5 Hz to 10 kHz |
| Linear Range | 2 mm (80 mils) |
| Power Supply | −17.5 VDC to −26 VDC |
| Current Consumption | Typically less than 12 mA |
| Input Impedance | Matched to 3300 NSv probe system |
| Housing Material | Molded industrial-grade polymer |
| Operating Temperature | −35°C to +85°C |
| Storage Temperature | −51°C to +100°C |
| Relative Humidity | 95% non-condensing |
| System Compatibility | Bently Nevada 3300 NSv Probe and Extension Cable |
| Application | Shaft vibration, shaft position, eccentricity, thrust position, and machinery protection systems |
| Dimensions (H × W × D) | Approx. 120 × 50 × 75 mm |
| Weight | Approx. 0.30 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Bently Nevada 330903-00-05-50-02-00 used for?
It is a 3300 NSv Proximitor® Sensor used to convert signals from an NSv proximity probe into calibrated outputs for vibration and position monitoring.
Q2: What does option 05 indicate?
Option 05 specifies the panel-mount version of the Proximitor® sensor.
Q3: What does option 50 indicate?
Option 50 specifies a 5.0-meter calibrated transducer system length.
Q4: Which probes are compatible with this sensor?
It is designed for use with Bently Nevada 3300 NSv proximity probes and matching extension cables.
Q5: What output sensitivity does this sensor provide?
The standard output sensitivity is 200 mV/mil (7.87 V/mm).
Q6: What power supply is required?
The sensor operates from a DC supply ranging from −17.5 VDC to −26 VDC.
Q7: What measurements can this sensor support?
It supports shaft vibration, shaft position, thrust position, eccentricity, and other proximity-based machinery monitoring measurements.
Q8: What should be verified before replacement?
Users should verify mounting type, system length, probe compatibility, extension cable configuration, power supply requirements, and monitoring system compatibility before installation.
