Technical Specifications
| Item | Specification |
|---|---|
| Model | Bently Nevada 3500/22-01-02-00 |
| Type | Transient Data Interface (TDI) Module |
| Product Category | Machinery Protection and Condition Monitoring |
| Product Family | 3500 Series |
| Function | System configuration, data collection, and transient data interface |
| Measurement Principle | Digital data acquisition and communication |
| Primary Role | Interface between 3500 rack and monitoring software |
| Data Functions | Steady-state and transient data capture |
| Communication Interface | Ethernet and serial communication |
| System Compatibility | 3500 Monitoring System racks |
| Power Requirement | Supplied by 3500 rack backplane |
| Installation Method | Rack-mounted module |
| Operating Temperature Range | –30 °C to +65 °C |
| Application Environment | Industrial machinery monitoring systems |
| Diagnostics | Self-monitoring and system status reporting |
| Dimensions | Standard 3500 module size |
| Weight | 0.68 kg |
FAQ
FAQ
Q1: What is the main purpose of the 3500/22-01-02-00 module?
It serves as the interface between the 3500 rack and external configuration and monitoring software.
Q2: Is the 3500/22-01-02-00 a sensor?
No, it is a Transient Data Interface module, not a sensor.
Q3: What type of data does this module handle?
It manages steady-state monitoring data and transient event data from the 3500 system.
Q4: How is the module installed?
It is installed directly into a slot of a 3500 series rack.
Q5: What communication methods does it support?
The module supports Ethernet and serial communication interfaces.
Q6: Does the module require an external power supply?
No, it receives power from the 3500 rack backplane.
Q7: What systems is this module compatible with?
It is fully compatible with Bently Nevada 3500 Series monitoring systems.
Q8: What are the dimensions and weight of the module?
It uses a standard 3500 module form factor and weighs 0.68 kg.
