Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Bently Nevada 3500/25 125800-02 |
| Type | Isolated Keyphasor I/O Module (Internal Terminations) |
| Function | Provides isolated Keyphasor signal input/output for machinery monitoring systems |
| Input Signals | Compatible with proximity probes and Keyphasor sensors |
| Output Signals | Isolated Keyphasor outputs to 3500 monitoring system |
| Isolation Voltage | 1500 V typical between input and output |
| Signal Processing | Real-time edge detection and pulse shaping |
| Diagnostic Features | Self-test and status monitoring |
| Protection Features | Overvoltage, EMI, and short-circuit protection |
| Communication Interface | Internal 3500 system bus |
| Power Consumption | <8 W typical |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Mounting Type | Rack or panel mount |
| Cooling Method | Natural convection |
| Compliance | CE and UL certified |
| Dimensions (HxWxD) | 241.3 × 24.4 × 103.1 mm |
| Weight | 0.46 kg |
FAQ
FAQ
Q1: What is the primary function of the Bently Nevada 3500/25 125800-02 module?
A1: This module provides isolated Keyphasor signal input and output, enabling accurate rotor speed and phase monitoring for machinery protection systems.
Q2: Which sensors can be connected to this module?
A2: It supports connection to Bently Nevada proximity probes and Keyphasor sensors, allowing integration with existing 3500 monitoring systems.
Q3: How does the module ensure signal integrity?
A3: Isolation between input and output circuits, along with overvoltage and EMI protection, ensures clean and reliable signal transmission.
Q4: Can this module perform self-diagnostics?
A4: Yes, it includes built-in self-test and status monitoring to verify proper operation and facilitate maintenance.
Q5: What type of signal processing does the module perform?
A5: It provides real-time edge detection and pulse shaping to produce accurate Keyphasor output signals suitable for monitoring system inputs.
Q6: How is the module integrated into the 3500 system?
A6: It connects via the internal 3500 system bus, allowing seamless communication and signal distribution within the monitoring architecture.
Q7: What protection features are implemented in this module?
A7: It has overvoltage, short-circuit, and electromagnetic interference protections to prevent damage and maintain reliable operation.
Q8: In what applications is this module typically used?
A8: It is used in turbine and generator monitoring, rotating machinery protection, and any system requiring precise Keyphasor signal isolation and processing.
