Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 3500/32 149986-02 + 125720-01 |
| Series | 3500 Series |
| Module Type | 4-Channel Relay Module |
| Relay Configuration | Each relay output can be configured for Normally Energized or Normally De-energized operation |
| Relay Type | SPDT (Single-Pole Double-Throw), epoxy-sealed, with 250 Vrms arc suppressor |
| Contact Life | 100,000 cycles at 5 A, 24 Vdc or 240 Vac |
| Power Consumption | 5.8 W typical |
| Alarm Drive Logic | Programmable using AND/OR logic |
| Installation | Full-height module, can be installed in any slot to the right of the Transient Data Interface Module |
| Dimensions | 241 × 24.4 × 242 mm |
| Weight | 0.7 kg |
FAQ
FAQ
-
What is the maximum current rating for each relay contact?
Each relay contact is rated for up to 5 A at 24 Vdc or 240 Vac. -
Can the relay outputs be individually programmed for different logic functions?
Yes, each of the four relays can be independently configured using AND/OR logic. -
What type of relays are used in this module?
The module uses SPDT (Single-Pole Double-Throw) epoxy-sealed relays with 250 Vrms arc suppressors. -
How many cycles can the relay contacts endure?
The relay contacts are rated for 100,000 operational cycles under specified load conditions. -
What is the typical power consumption of this module?
The module consumes approximately 5.8 W under normal operation. -
Can the module be installed in any slot within the 3500 Series system?
The module can be installed in any slot to the right of the Transient Data Interface Module. -
Are the relay outputs normally energized or de-energized?
Each relay output can be configured to operate as Normally Energized or Normally De-energized. -
What are the physical dimensions and weight of the module?
Dimensions are 241 × 24.4 × 242 mm, and the module weighs 0.7 kg.
