Technical Specifications
| Item | Specification |
|---|---|
| Product Type | Relay Module |
| Model Number | 3500/33M |
| Part Number | 149986-01 |
| Channels | 16 channels |
| Input Voltage Range | 24 VDC (from monitoring system) |
| Output Type | Dry-contact relay output |
| Relay Capacity | 2 A @ 30 VDC / 0.5 A @ 120 VAC |
| Response Time | 5 ms (typical) |
| Operating Temperature | 0 °C to 70 °C |
| Storage Temperature | -40 °C to 85 °C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | 241 x 24.4 x 242 mm |
| Weight | 0.7 kg |
| Mounting | 19-inch rack or DIN rail |
| Applications | For monitoring system alarms, fault indication, and logic control |
FAQ
FAQ
Q1: What is the main function of the 3500/33M 16-channel relay module?
It is used for alarms, fault indication, and logic control in monitoring systems.
Q2: How many channels does the module have?
It has 16 independent relay channels.
Q3: What type of output does it provide?
Dry-contact relay output.
Q4: What is the capacity of each relay?
Each relay is rated at 2 A @ 30 VDC or 0.5 A @ 120 VAC.
Q5: What is the operating temperature range?
0 °C to 70 °C.
Q6: What are the power requirements?
Powered by 24 VDC from the monitoring system.
Q7: What are the dimensions and weight?
Dimensions: 241 x 24.4 x 242 mm; Weight: 0.7 kg.
Q8: How can it be mounted?
It can be mounted on a 19-inch rack or DIN rail.
