Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Bently Nevada 3500/42-01-CN 3500 Series Proximitor Seismic Monitor |
| Channels | 4 independent channels |
| Supported Measurements | Radial Vibration, Thrust Position, Eccentricity, Differential Expansion, Acceleration, Velocity |
| Supported Transducers | Proximitor® and Seismic transducers (including Bently Nevada 7200, 3300, 3000 series, Velomitor, High Temperature Velomitor, Acceleration Interface Modules) |
| Alarm Types | Alert (Alarm 1), Danger (Alarm 2) |
| Alarm Processing | Latching / Non-latching, programmable setpoints |
| Configuration | Via 3500 Rack Configuration Software |
| I/O Module Options | Internal Termination, External Termination, Internal Barrier I/O Module, External Barrier options |
| Power Supply | Powered via 3500 rack backplane |
| Communication | Through 3500 rack system interfaces |
| Installation | 3500 rack slot 2–15, supports TMR (Triple Modular Redundant) configuration |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 95% non-condensing |
| Dimensions | 241.3 x 24.4 x 241.8 mm |
| Weight | 0.91 kg |
FAQ
FAQ
Q1: What measurement functions does the 3500/42-01-CN support?
A1: It supports radial vibration, thrust position, eccentricity, differential expansion, acceleration, and velocity measurements.
Q2: Is the module compatible with all Bently Nevada sensors?
A2: Yes, it works with Bently Nevada Proximitor® and seismic transducers, including 7200, 3300, and 3000 series, as well as Velomitor types.
Q3: What alarm types are available on this monitor?
A3: It provides two alarm levels: Alert (Alarm 1) and Danger (Alarm 2), configurable as latching or non-latching.
Q4: How is this module configured?
A4: Configuration is performed via the 3500 Rack Configuration Software, allowing channel type and alarm settings to be customized.
Q5: Does it support Triple Modular Redundant (TMR) applications?
A5: Yes, it can be used with TMR I/O modules in a triple modular redundant system to enhance reliability.
Q6: What are the installation requirements?
A6: It must be installed in rack slots 2 through 15, using the correct I/O modules and shielded wiring.
Q7: What is the operating temperature range?
A7: The operating temperature range is -30°C to +65°C, and the storage range is -40°C to +85°C.
Q8: What are the dimensions and weight of the module?
A8: It measures 241.3 x 24.4 x 241.8 mm and weighs 0.91 kg.
