Technical Specifications
| Parameter | Description |
|---|---|
| Module Type | Temperature Input Module |
| Part Numbers | 163179-01 (Module), 136711-01 (Associated Component) |
| Series | Bently Nevada 3500 Series |
| Number of Channels | 4 channels, independent measurement |
| Input Types | Thermocouple (Type E, J, K, T, B, R, S) and RTD (2-wire, 3-wire, 4-wire) |
| Input Range | -200°C to +1800°C (depending on sensor type) |
| Accuracy | ±0.1% of full scale |
| Update Rate | 1 second per channel |
| Alarm Modes | High, Low, and Rate-of-Change alarms per channel |
| Communication Interface | Proprietary 3500 rack backplane interface |
| Power Consumption | < 5 W |
| Operating Temperature Range | -30°C to +65°C |
| Storage Temperature Range | -40°C to +85°C |
| Dimensions (H x W x D) | 241.3 × 24.4 × 241.8 mm |
| Weight | 0.91 kg |
FAQ
FAQ
Q1: What is the primary function of the Bently Nevada 3500/60 Temperature Module?
A1: It provides continuous temperature monitoring for rotating machinery and other critical equipment, integrating with the 3500 Series system for alarm and shutdown functions.
Q2: Which sensor types are compatible with this module?
A2: It supports multiple thermocouple types (E, J, K, T, B, R, S) and RTDs in 2-, 3-, and 4-wire configurations.
Q3: How many channels does the module provide, and are they independent?
A3: The module offers 4 fully independent input channels, each configurable for specific sensor types.
Q4: What is the measurement accuracy for temperature inputs?
A4: The accuracy is ±0.1% of full scale, ensuring high reliability in industrial monitoring applications.
Q5: How are alarms configured in the module?
A5: Each channel supports high, low, and rate-of-change alarm settings, programmable via the 3500 Configuration Software.
Q6: Is the module hot-swappable within the 3500 rack?
A6: Yes, it is designed for hot-swapping without interrupting other rack operations, minimizing downtime.
Q7: What environmental conditions can the module withstand?
A7: It operates in temperatures from -30°C to +65°C and can be stored between -40°C and +85°C.
Q8: Does the module require external power?
A8: No, it draws power directly from the 3500 rack backplane, with consumption below 5 W.
