Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | 60R/CHA02 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Product Series | Orbit 60 Series |
| Product Type | System Chassis (3U Panel Mount) |
| Main Function | Provides mechanical mounting and backplane connectivity for Orbit 60 modules |
| Chassis Type | 3U panel-mount chassis |
| Slot Capacity | Up to 10 module slots (depending on configuration) |
| Compatible Modules | SIM, PPM, CMM, PIM, I/O modules, communication modules |
| System Compatibility | Orbit 60 machinery protection and condition monitoring system |
| Backplane Interface | Integrated backplane for module communication and power distribution |
| Mounting Options | Panel mount or rack mount installation |
| Front Panel Features | Status LEDs, reset button, configuration/run key switch |
| Wiring Method | Rear wiring connections on utility side |
| Operating Temperature | 0°C to +65°C |
| Storage Temperature | −40°C to +85°C |
| Dimensions (Chassis) | Approx. 483 mm × 132 mm × 300 mm |
| Weight | Approximately 4.5 kg |
| Certification Options | SIL safety level options and country-specific approvals |
| Typical Applications | Turbines, compressors, pumps, generators, and industrial rotating machinery monitoring |
FAQ
FAQ
Q1. What is the purpose of the 60R/CHA02 chassis?
It provides the physical housing and backplane connections required to install Orbit 60 monitoring modules.
Q2. Which system uses this chassis?
It is designed for the Bently Nevada Orbit 60 machinery protection and condition monitoring system.
Q3. How many modules can the chassis support?
A typical configuration supports multiple modules through general-purpose slots, depending on the system layout.
Q4. What type of installation does the 60R/CHA02 support?
It is designed for panel or rack mounting in control cabinets.
Q5. Where are wiring connections located on the chassis?
All wiring and connections are made on the rear utility side of the chassis.
Q6. What modules can be installed in the chassis?
Modules such as system interface modules, protection processing modules, power input modules, and sensor input modules can be installed.
Q7. What industries commonly use the Orbit 60 chassis?
It is widely used in oil and gas, power generation, petrochemical, and other heavy industries with rotating machinery.
Q8. Why is the chassis important in a monitoring system?
The chassis provides structural support, power distribution, and communication pathways for all modules in the monitoring system.
