Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | 74712-01-02-04-04 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Product Type | Vibration Transmitter |
| Measurement Type | Machinery vibration monitoring |
| Input Signal | Accelerometer or vibration sensor input |
| Output Signal | 4–20 mA analog output proportional to vibration level |
| Measurement Range | Configurable depending on sensor and application |
| Frequency Response | Typical industrial vibration monitoring range |
| Power Supply | 18–30 VDC |
| Output Type | Loop-powered current output |
| Signal Processing | RMS vibration measurement and signal conditioning |
| Installation Method | DIN rail or panel mounting |
| Electrical Connection | Screw terminal connections |
| Operating Temperature | −20°C to +70°C |
| Storage Temperature | −40°C to +85°C |
| Dimensions | Approx. 120 mm × 80 mm × 40 mm |
| Weight | Approximately 0.35 kg |
| Typical Applications | Pumps, motors, fans, compressors, turbines, and rotating machinery condition monitoring |
FAQ
FAQ
Q1. What is the main function of the 74712-01-02-04-04 device?
It converts vibration signals from sensors into a 4–20 mA signal that can be used by control and monitoring systems.
Q2. What type of sensors can be connected to this transmitter?
It is typically used with accelerometers or other vibration sensors for rotating machinery monitoring.
Q3. What output signal does the transmitter provide?
The device provides a standard 4–20 mA analog output representing vibration levels.
Q4. How is the device powered?
It operates with a DC power supply in the range of 18–30 VDC.
Q5. Where is the transmitter usually installed?
It is commonly installed inside control cabinets using DIN rail or panel mounting.
Q6. What equipment commonly uses this transmitter?
It is used on pumps, motors, compressors, turbines, and other rotating equipment.
Q7. What temperature range can the device operate in?
The operating temperature range is −20°C to +70°C.
Q8. Why are vibration transmitters important in industrial systems?
They allow continuous monitoring of machinery vibration, helping detect mechanical problems before equipment failure occurs.
