Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | 74712-07-02-04-04 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Product Type | Vibration Transmitter |
| Measurement Type | Machinery vibration monitoring |
| Input Signal | Accelerometer or vibration sensor input |
| Output Signal | 4–20 mA analog output proportional to vibration amplitude |
| Measurement Range | Configurable depending on connected sensor and application |
| Frequency Response | Suitable for industrial vibration monitoring ranges |
| Power Supply | 18–30 VDC |
| Output Type | Loop-powered current output |
| Signal Processing | RMS vibration measurement with signal conditioning |
| Installation Method | DIN rail or panel mounting |
| Electrical Connection | Screw terminal connections |
| Operating Temperature | −20°C to +70°C |
| Storage Temperature | −40°C to +85°C |
| Dimensions | Approx. 120 mm × 80 mm × 40 mm |
| Weight | Approximately 0.35 kg |
| Typical Applications | Pumps, motors, compressors, turbines, and rotating machinery condition monitoring |
FAQ
FAQ
Q1. What is the main function of the 74712-07-02-04-04 transmitter?
It converts vibration signals from sensors into a 4–20 mA output for machinery monitoring systems.
Q2. Which sensors are compatible with this transmitter?
It works with accelerometers and other vibration sensors installed on rotating machinery.
Q3. What type of output does the device provide?
It provides a 4–20 mA analog signal proportional to vibration levels.
Q4. What power supply is required for this transmitter?
It operates on 18–30 VDC.
Q5. How is the transmitter installed?
It is mounted on a DIN rail or panel inside a control cabinet.
Q6. What types of equipment use this transmitter?
It is used for vibration monitoring on pumps, motors, fans, compressors, and turbines.
Q7. What is the operating temperature range?
The operating range is −20°C to +70°C.
Q8. Why is a vibration transmitter important in industrial monitoring systems?
It provides continuous vibration data, allowing early detection of mechanical faults and preventing unexpected equipment failures.
