Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | 86691-01250-0400-15-06 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Product Type | Vibration Transmitter / Sensor Interface |
| Measurement Type | Machinery vibration and position monitoring |
| Input Signal | Vibration or displacement sensors (accelerometers, proximity probes) |
| Output Signal | 4–20 mA analog output proportional to measured vibration or displacement |
| Measurement Range | Configurable depending on sensor and application |
| Frequency Response | Industrial vibration monitoring range |
| Power Supply | 18–30 VDC |
| Output Type | Loop-powered 4–20 mA |
| Signal Processing | RMS measurement and signal conditioning |
| Installation Method | DIN rail or panel mounting |
| Electrical Connection | Screw terminals |
| Operating Temperature | −20°C to +70°C |
| Storage Temperature | −40°C to +85°C |
| Dimensions | Approx. 120 mm × 80 mm × 40 mm |
| Weight | Approximately 0.35 kg |
| Typical Applications | Pumps, compressors, motors, turbines, and rotating machinery condition monitoring |
FAQ
FAQ
Q1. What is the main function of the 86691-01250-0400-15-06 transmitter?
It converts vibration or displacement sensor signals into a 4–20 mA output for machinery monitoring.
Q2. Which sensors can be used with this transmitter?
It supports accelerometers and eddy current proximity probes.
Q3. What type of output does the device provide?
It provides a loop-powered 4–20 mA analog output proportional to measured vibration or displacement.
Q4. What power supply does the device require?
It operates with 18–30 VDC.
Q5. Where is the transmitter installed?
It is mounted on a DIN rail or panel inside a control cabinet.
Q6. What equipment typically uses this transmitter?
It is used on pumps, motors, compressors, turbines, and other rotating machinery.
Q7. What is the operating temperature range?
The transmitter operates between −20°C and +70°C.
Q8. Why is a vibration transmitter important in industrial monitoring?
It provides continuous vibration data, enabling early fault detection and safe operation of rotating machinery.
