Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider 991‑06‑50‑01‑05 |
| Type | Discrete Output Module |
| Product Category | PLC Output Module |
| Product Family | Modicon 990 Series / Advanced PLC I/O |
| Function | Provides discrete DC output signals for field devices |
| Number of Output Channels | 6 outputs |
| Output Voltage Range | 24 V DC nominal |
| Output Logic | Positive logic (sourcing) |
| Maximum Load Current | 50 mA per channel |
| Total Load Current | Approx. 0.3 A |
| Status Indication | Individual LED indicators for each output channel |
| Output Protection | Overcurrent/short‑circuit protection per channel |
| Mounting Method | DIN rail or control panel mount via 990 base |
| Field Wiring Connection | Screw terminal or spring‑clamp terminals |
| Operating Temperature Range | 0 °C to +60 °C |
| Storage Temperature Range | –20 °C to +70 °C |
| Protection Rating | IP20 |
| Housing Material | Industrial‑grade plastic |
| Application Environment | Industrial automation and machine control |
| Compatibility | Modicon 990 PLC I/O rack and base modules |
| Dimensions | Approx. 90 mm × 45 mm × 60 mm |
| Weight | Approximately 0.18 kg |
FAQ
FAQ
Q1: What is the main purpose of the 991‑06‑50‑01‑05 module?
It provides six discrete DC output channels used to drive small loads such as signal lamps, indicators, and logic‑level actuators in automation systems.
Q2: How many output channels does this module have?
It has 6 discrete DC output channels.
Q3: What output voltage does the module support?
The outputs are designed for a nominal 24 V DC supply voltage.
Q4: What is the maximum current per channel?
Each output channel can handle up to 50 mA of load current.
Q5: Does the module include status indication?
Yes, each output has its own LED indicator showing whether the output is active.
Q6: What type of protection does the module provide?
It provides basic overcurrent and short‑circuit protection per output channel.
Q7: In what environments is this module suitable for use?
It is suitable for industrial automation environments and control cabinet installation.
Q8: What are the physical dimensions and weight of the 991‑06‑50‑01‑05?
The module measures approximately 90 mm × 45 mm × 60 mm and weighs about 0.18 kg.
