Technical Specifications
| Item | Specification |
|---|---|
| Model | Bently Nevada 991-06-XX-01-01 |
| Series | 991 Thrust Sensor |
| Measurement Type | Shaft thrust / axial displacement monitoring |
| Input Signal | Eddy current displacement probe signal |
| Measurement Range | Depends on probe configuration (typically ±2 mm to ±5 mm) |
| Sensitivity | 200 mV/mil or equivalent (depending on probe type) |
| Output Signal | 4–20 mA current signal (isolated) |
| Output Load | Up to 600 Ω |
| Power Supply | 24 VDC nominal, range 18–36 VDC |
| Power Consumption | ≤ 3 W |
| Frequency Response | DC to 10 kHz |
| Accuracy | ±1% of full scale |
| Response Time | ≤ 200 ms |
| Temperature Range | Operating: -25 °C to +70 °C; Storage: -40 °C to +85 °C |
| Humidity Range | 5–95% non-condensing |
| EMC Compliance | Meets industrial EMC standards |
| Mounting | DIN rail 35 mm |
| Enclosure Material | Industrial-grade flame-retardant plastic |
| Protection Level | IP20 |
| Dimensions | 100.1 x 73.9 x 53.3 mm |
| Weight | 0.43 kg |
FAQ
FAQ
Q1: What is the main function of the 991-06-XX-01-01?
A1: It monitors thrust position or axial displacement in rotating machinery to ensure safe operation.
Q2: What does “XX” represent in the model number?
A2: “XX” indicates configurable options, usually related to range, sensor compatibility, or application requirements.
Q3: What type of output signal does it provide?
A3: It provides an isolated 4–20 mA current signal for integration with PLC or DCS systems.
Q4: Is it suitable for continuous operation?
A4: Yes, it is designed for critical industrial equipment and supports long-term continuous operation.
Q5: What are the common applications?
A5: It is widely used in turbines, compressors, generators, and large motors for thrust monitoring.
Q6: How strong is its EMC performance?
A6: It meets industrial EMC standards, ensuring reliable operation in high-interference environments.
Q7: Is the installation method flexible?
A7: Yes, it supports DIN rail mounting for easy integration into industrial control panels.
Q8: What are the dimensions and weight of the unit?
A8: The dimensions are 100.1 x 73.9 x 53.3 mm, and the weight is 0.43 kg.
