Emerson KJ2231X1-BB1 Relay Module

FAQ

Q1: What type of module is the Emerson KJ2231X1-BB1?
A: It is a 16-channel relay output module used for controlling contactors, indicators, and other switch-type loads.

Q2: What is the output capacity per channel?
A: Each channel can handle up to 2 A for loads up to 250 VAC or 24 VDC.

Q3: Does it provide isolation protection?
A: Yes, all channels are optically isolated for enhanced system safety.

Q4: Is it compatible with the DeltaV system?
A: Yes, it is fully compatible and designed for slot mounting in Emerson DeltaV systems.

Q5: Are there LED indicators on the module?
A: Yes, each channel features an LED status indicator for operational monitoring.

Q6: Does it support redundancy?
A: The module itself is not redundant, but it can be used in a redundant system configuration.

Q7: What type of loads is it suitable for?
A: It is ideal for dry-contact control of switch-based loads like motor starters, alarms, and relays.

Q8: What are the dimensions and weight of the module?
A: It measures 36 x 229 x 51 mm and weighs approximately 0.4 kg.
