Technical Specifications
| Item | Description |
|---|---|
| Manufacturer | Emerson |
| Product Model | KJ3003X1-BA1 |
| Product Type | Serial Interface Card |
| Interface Type | RS-232 / RS-485 Serial Communication |
| Supported Protocols | Modbus RTU, DeviceNet (optional depending on configuration) |
| Baud Rate | 9600–115200 bps |
| Number of Ports | 1 serial port |
| Isolation Voltage | 1500 VAC between port and backplane |
| Status Indicators | LED indicators for port activity and communication status |
| Backplane Compatibility | Emerson DeltaV Rack System |
| Power Requirements | Supplied by DeltaV rack backplane |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting Type | Rack-mounted (DeltaV backplane) |
| Dimensions | 120 x 70 x 55 mm |
| Weight | 0.18 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the Emerson KJ3003X1-BA1 used for?
It is used to provide serial communication capability (RS-232/RS-485) for Emerson DeltaV control systems.
Q2: Which protocols are supported by this card?
It supports Modbus RTU and optionally DeviceNet, depending on system configuration.
Q3: How many serial ports does it have?
The card has one serial communication port.
Q4: What is the supported baud rate range?
It supports baud rates from 9600 to 115200 bps.
Q5: Is the serial interface isolated from the backplane?
Yes, it provides 1500 VAC isolation between the serial port and backplane.
Q6: How is communication status indicated?
LED indicators show port activity and communication status.
Q7: Can this card be used with other DeltaV modules?
Yes, it is fully compatible with Emerson DeltaV rack systems and other I/O modules.
Q8: What are the environmental operating requirements?
Operating temperature is 0–60°C with 5–95% relative humidity (non-condensing).
