Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Emerson KJ4006X1-BS1 |
| Product Type | Redundant Analog Input 8-Channel Terminal Block |
| Channels | 8 |
| Power Supply | Dual DC/DC |
| Field Power | 30 VDC at 200 mA |
| Ambient Temperature Range | -40°C to +70°C |
| Shock Resistance | 10g, ½ sine wave for 11 ms |
| Vibration Resistance | 1 mm (2–13.2 Hz), 0.7 g (13.2–150 Hz) |
| Humidity Range | 5% to 95%, non-condensing |
| Contaminant Resistance | ISA-S71.04 –1985 G3 Class |
| Terminal Block Keying | Rotary keying system matched to I/O card |
| Maintenance | No user-serviceable parts, no calibration required |
| Safety Certifications | ATEX, IECEx, FM (US & Canada), UKEX |
| Dimensions (W x H x D) | 146 x 70 x 35 mm |
| Weight | 0.3 kg |
FAQ
FAQ
Q1: Does the Emerson KJ4006X1-BS1 support redundancy?
A1: Yes, it is a redundant analog input terminal block designed to support high-availability systems.
Q2: How many analog input channels does this terminal block support?
A2: It supports 8 analog input channels.
Q3: Can the terminal block be inserted or removed while the system is powered?
A3: Only when no I/O card is installed and no field wiring is connected can it be safely inserted or removed under power.
Q4: Is calibration required for this product?
A4: No calibration is needed. The unit is pre-calibrated and maintenance-free.
Q5: What are the environmental conditions for proper operation?
A5: Operating temperature range is -40°C to +70°C with relative humidity between 5% and 95% (non-condensing).
Q6: Does the product provide vibration resistance?
A6: Yes, it meets 1 mm peak-to-peak vibration from 2–13.2 Hz and 0.7 g from 13.2–150 Hz.
Q7: What certifications does the KJ4006X1-BS1 comply with?
A7: It is certified by ATEX, IECEx, FM (US & Canada), and UKEX for use in hazardous locations.
Q8: Are there any user-serviceable parts inside the device?
A8: No, the product contains no user-serviceable components and should not be disassembled.
