Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | SE4001S2T2B2 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Discrete Output Module with Fused 8-Channel Terminal Block |
| Application | Digital Actuation and Control with Circuit Protection |
| Output Channels | 8 Channels |
| Output Voltage | 24 VDC Nominal |
| Output Current | Up to 500 mA per Channel |
| Load Type | Resistive or Inductive Loads |
| Isolation Voltage | 500 VDC Between Channels and Ground |
| Response Time | Less than 5 ms |
| Wiring Size | 16 AWG to 20 AWG |
| Power Consumption | Less than 3 W |
| MTBF | Greater than 100,000 Hours |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Terminal Block Type | Fused 8-Channel Output Terminal Block |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | Approximately 100 mm × 120 mm × 30 mm |
| Weight | Approximately 0.28 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson SE4001S2T2B2 used for?
The SE4001S2T2B2 is used to control digital field devices while providing circuit protection through integrated fusing. It is suitable for relays, solenoids, indicators, and other actuators within a DeltaV control system.
Q2: How many output channels does the module have?
The module provides 8 discrete output channels.
Q3: What is the output voltage and current?
The module operates at 24 VDC and can deliver up to 500 mA per channel.
Q4: What types of loads can it drive?
It can drive resistive or inductive loads, including relays, solenoids, and small indicator lamps.
Q5: What are the dimensions of the SE4001S2T2B2?
The module measures approximately 100 mm × 120 mm × 30 mm.
Q6: How much does the module weigh?
The SE4001S2T2B2 weighs approximately 0.28 kg.
Q7: Can it operate in industrial environments?
Yes, it is rated for -20°C to +70°C operating temperature and 5%–95% non-condensing humidity.
Q8: Does the module require calibration or routine maintenance?
No calibration is required. Regular inspection of terminal connections, wiring, and fuses is sufficient to maintain reliable operation.
