Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | SE4001S3T1B1 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Discrete Input Module with 8-Channel Terminal Block (Type 3) |
| Application | Digital Signal Monitoring and Acquisition |
| Input Channels | 8 Channels |
| Input Voltage | 24 VDC Nominal |
| Input Current | Up to 10 mA per Channel |
| Isolation Voltage | 500 VDC Between Channels and Ground |
| Response Time | Less than 5 ms |
| Wiring Size | 16 AWG to 20 AWG |
| Power Consumption | Less than 1.5 W |
| MTBF | Greater than 100,000 Hours |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Terminal Block Type | 8-Channel Terminal Block |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | Approximately 100 mm × 120 mm × 30 mm |
| Weight | Approximately 0.25 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson SE4001S3T1B1 used for?
The SE4001S3T1B1 is used to monitor digital input signals from field devices such as switches, relays, and contact sensors within a DeltaV control system.
Q2: How many input channels does the module have?
The module provides 8 discrete input channels.
Q3: What is the input voltage for the SE4001S3T1B1?
The module operates at a nominal 24 VDC, compatible with standard industrial digital inputs.
Q4: What are the dimensions of the module?
The module measures approximately 100 mm × 120 mm × 30 mm.
Q5: How much does the SE4001S3T1B1 weigh?
The unit weighs approximately 0.25 kg.
Q6: Can the module operate in harsh industrial conditions?
Yes, it operates between -20°C and +70°C and supports relative humidity from 5% to 95% non-condensing.
Q7: Does the SE4001S3T1B1 provide electrical isolation?
Yes, it provides 500 VDC isolation between channels and ground to protect the system from electrical noise and transients.
Q8: Does the SE4001S3T1B1 require calibration or routine maintenance?
No routine calibration is required. Periodic inspection of wiring and terminal connections is sufficient for reliable operation.
