Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | SE4001S3T2B3 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | Discrete Input Module with High-Density 16-Channel Terminal Block |
| Application | Digital Signal Monitoring and Acquisition |
| Input Channels | 16 Channels |
| Input Voltage | 24 VDC Nominal |
| Input Current | Up to 10 mA per Channel |
| Isolation Voltage | 500 VDC Between Channels and Ground |
| Response Time | < 5 ms |
| Wiring Size | 16 AWG to 22 AWG |
| Power Consumption | < 2.5 W |
| MTBF | > 100,000 Hours |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Terminal Block Type | High-Density 16-Channel Terminal Block |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | ~150 mm × 120 mm × 30 mm |
| Weight | ~0.40 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson SE4001S3T2B3 used for?
It is used to read digital ON/OFF signals from field devices such as switches, sensors, and relay contacts.
Q2: How many input channels does it have?
The module provides 16 discrete input channels.
Q3: What is the input voltage rating?
It operates at 24 VDC nominal for standard industrial digital signals.
Q4: What is the difference between this and 8-channel versions?
The SE4001S3T2B3 provides double the channel density (16 vs 8 channels), reducing cabinet space and wiring footprint.
Q5: What are the module dimensions?
Approximately 150 mm × 120 mm × 30 mm.
Q6: What is the weight?
Approximately 0.40 kg.
Q7: Can it operate in harsh environments?
Yes, it supports -20°C to +70°C operating temperature and up to 95% non-condensing humidity.
Q8: Does it require calibration or maintenance?
No calibration is required. Routine inspection of wiring and terminals is sufficient for reliable operation.
