Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4001S2T1B3 |
| Product Type | Discrete Input Card |
| Manufacturer | Emerson |
| Series | VE4000 Series |
| Input Type | Discrete / Digital |
| Number of Channels | 8 isolated channels |
| Input Voltage Range | 24 VDC nominal |
| Input Signal Type | Sinking or sourcing |
| Input Current | 6 mA typical per channel |
| Isolation | 2500 V RMS channel-to-channel and channel-to-system |
| Input Delay (ON/OFF) | ≤ 1 ms |
| Power Supply Voltage | 24 VDC nominal |
| Logic Levels | Logic 1: ≥ 15 VDC, Logic 0: ≤ 5 VDC |
| Status Indicators | One LED per input channel |
| Diagnostics | Built-in self-test and communication check |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Mounting Type | System backplane or DIN rail |
| Compatibility | DeltaV and Ovation systems |
| Certifications | CE, UL, CSA, ATEX |
| Dimensions | 107 × 41 × 105 mm |
| Weight | 0.36 kg |
FAQ
FAQ
Q1: What is the main function of the Emerson VE4001S2T1B3 Discrete Input Card?
A1: The module is designed to receive digital or discrete signals from field devices such as limit switches, push buttons, and sensors, transmitting their ON/OFF states to the control system.
Q2: How many discrete input channels does this card support?
A2: It provides 8 fully isolated input channels, each capable of independent signal detection and isolation, ensuring high system reliability and signal integrity.
Q3: What type of input voltage is supported by this module?
A3: The card supports a nominal 24 VDC input voltage, making it suitable for a wide range of standard industrial discrete devices.
Q4: Does the VE4001S2T1B3 module include built-in diagnostics?
A4: Yes, it features internal diagnostics that monitor input health, communication status, and card performance to ensure system integrity and early fault detection.
Q5: Can the card be used with both sourcing and sinking input devices?
A5: Yes, the module supports both sourcing and sinking configurations, offering flexibility for integration with various field device types.
Q6: What is the isolation protection level between channels?
A6: Each input channel is isolated up to 2500 V RMS, providing robust protection against noise, surges, and electrical interference from other signals.
Q7: Is the VE4001S2T1B3 compatible with Emerson control platforms?
A7: It is fully compatible with Emerson’s DeltaV and Ovation control systems, allowing for seamless integration and reliable performance in automation environments.
Q8: What is the typical response time for the input channels?
A8: The input response time is typically less than 1 millisecond, enabling fast signal processing for precise control applications.
