Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4001S2T2B4 KJ3203X1-BA1 |
| Product Type | Discrete Input Card |
| Manufacturer | Emerson |
| Series | VE4000 Series |
| Input Type | Dry contact (potential-free contact) |
| Number of Channels | 32 isolated input channels |
| Input Voltage Range | 24 VDC nominal |
| Input Signal Type | Normally open (NO) or normally closed (NC) contacts |
| Input Current | 6 mA typical per channel |
| Isolation Protection | 2500 V RMS channel-to-channel and channel-to-system |
| Input Delay (ON/OFF) | ≤ 1 ms |
| Power Supply Voltage | 24 VDC nominal |
| Logic Levels | Logic 1: Contact closed, Logic 0: Contact open |
| Status Indicators | LED indicator per channel |
| Diagnostics | Built-in self-diagnostic and fault detection |
| Terminal Blocks | Removable terminal blocks for easy wiring |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Mounting Type | DIN rail or backplane mounting |
| Compatibility | DeltaV and Ovation control systems |
| Certifications | CE, UL, CSA |
| Dimensions | 107 x 41 x 105 mm |
| Weight | 0.132 kg |
FAQ
FAQ
Q1: What is the function of the VE4001S2T2B4 discrete input card?
A1: This module collects signals from field devices through dry contacts, isolates each input channel, and relays them to the control system for accurate process monitoring and automation.
Q2: How many input channels does this card have, and are they isolated?
A2: The card features 32 fully isolated channels, ensuring that a fault or short circuit on one channel does not impact the others or the overall system.
Q3: What types of input signals are supported?
A3: It supports potential-free dry contact signals, including both normally open (NO) and normally closed (NC) contacts, which are standard in industrial automation.
Q4: Does the module provide electrical isolation?
A4: Yes, it provides 2500 V RMS isolation between channels and between each channel and the system, enhancing protection against electrical noise and surges.
Q5: How can I monitor the status of individual channels?
A5: Each input channel has a dedicated LED indicator that shows the current state of the contact, providing immediate visual feedback.
Q6: Is this module compatible with Emerson control systems?
A6: Yes, it is designed for full compatibility with Emerson DeltaV and Ovation systems, ensuring easy integration into existing automation networks.
Q7: What diagnostics features are included?
A7: The module offers built-in diagnostics that can detect wiring faults, open circuits, or channel failures, allowing timely maintenance and reliable operation.
Q8: How is field wiring connected to this card?
A8: Field devices are wired through removable terminal blocks, which simplify installation, replacement, and maintenance without disturbing adjacent modules.
