Technical Specifications
| scope | Specification |
|---|---|
| Model | VE4001S3T2B2 |
| Equipment type | Independent input card |
| Input Channel | 16 independent discrete inputs |
| Input voltage range | 24 V DC nominal value (18–32 V DC) |
| Input current | Typical current per channel is 5 mA |
| Input isolation | The voltage between channels and between channels and ground is 250 V RMS. |
| Input type | Dry contact or open collector |
| Input response time | Less than 1 millisecond |
| Diagnostic features | Channel status and fault detection |
| Power consumption | Typical value 3 watts |
| Operating temperature | -20°C to 60°C |
| Storage temperature | -40°C to 85°C |
| humidity | 5% – 95% Non-condensing |
| Protection level | IP20 |
| obey | CE, UL, ATEX certification |
| System compatibility | DeltaV and Emerson SIS systems |
| aspect | 107 × 41 × 105 mm |
| weight | 0.36 kg |
FAQ
Frequently Asked Questions
Q1: What are the main functions of the VE4001S3T2B2?
The VE4001S3T2B2 is a discrete input card used to detect the on/off status signals of field devices in Emerson DeltaV and SIS control systems.
Q2: How many input channels does this module provide?
It provides 16 independent isolated input channels for monitoring digital signals.
Q3: What is the nominal input voltage range for each channel?
The nominal operating voltage for each input channel is 24 V DC, with an effective range of 18 V to 32 V DC.
Q4: Does the VE4001S3T2B2 provide channel isolation?
Yes, this module provides 250V RMS isolation between channels and between channels and ground for enhanced safety.
Q5: What is the response time of the discrete input?
The response time of the input channel is less than 1 millisecond, which enables fast signal processing.
Q6: Can the VE4001S3T2B2 detect faults or line problems?
Yes, it has built-in channel status and fault detection and diagnostic functions to improve system reliability.
Q7: Which systems is this input card compatible with?
It is designed to work with Emerson’s DeltaV and SIS (Safety Instrumented System) architectures.
Q8: Under what environmental conditions can the VE4001S3T2B2 operate?
This module can operate reliably in environments with temperatures ranging from -20°C to 60°C and humidity levels up to 95% (non-condensing).
