Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4001S5T2B5 |
| Product Type | Discrete Input Card |
| Manufacturer | Emerson Process Management |
| Series | DeltaV System |
| Function | Provides isolated discrete input channels for process control |
| Number of Channels | 16 isolated digital input channels |
| Input Type | Discrete (on/off) |
| Signal Voltage Range | 18 to 32 VDC |
| Input Threshold (On/Off) | ON: >15 VDC / OFF: <5 VDC |
| Input Current per Channel | 2.0 mA (typical) |
| Isolation | 250 V RMS channel-to-bus and channel-to-ground |
| Update Time | 50 ms (typical) |
| Module Power Requirement | 5 V DC, 1.2 W (typical) |
| Power Dissipation | 1.5 W maximum |
| System Compatibility | Fully compatible with DeltaV and CHARMs systems |
| Status Indicators | Individual channel LEDs for diagnostics and signal status |
| Built-in Diagnostics | Channel fault detection and self-test functionality |
| Configuration | Software-configurable via DeltaV Explorer |
| Operating Temperature Range | -40°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting Type | Installed in DeltaV carrier or system baseplate |
| Certifications | CE, UL, CSA, and ATEX approved |
| Dimensions | 107 × 41 × 105 mm |
| Weight | 0.25 kg |
FAQ
FAQ
Q1: What is the main purpose of the Emerson VE4001S5T2B5 module?
A1: The VE4001S5T2B5 serves as a discrete input card that captures on/off digital signals from field devices and communicates them to the DeltaV control system for logic processing and automation tasks.
Q2: How many channels does the VE4001S5T2B5 provide?
A2: It offers 16 isolated discrete input channels, allowing reliable signal acquisition from multiple field instruments or switches simultaneously.
Q3: What voltage range is supported by each input channel?
A3: Each input channel accepts a DC voltage signal within the range of 18 to 32 VDC, with defined thresholds for ON and OFF detection to ensure accurate signal interpretation.
Q4: Is the module electrically isolated?
A4: Yes, the module provides 250 V RMS isolation between each input channel, the system bus, and ground, ensuring electrical safety and noise immunity.
Q5: How is diagnostic information communicated?
A5: Each input channel features an LED indicator for real-time signal and fault status, while advanced diagnostics are available through the DeltaV system software interface.
Q6: Can the VE4001S5T2B5 be configured through software?
A6: Yes, it can be configured using DeltaV Explorer, allowing flexible channel assignment, fault management, and input filtering through the software interface.
Q7: What kind of field devices are typically connected to this module?
A7: Commonly connected devices include limit switches, push buttons, proximity sensors, and status contacts from valves or actuators.
Q8: What are the main advantages of using the VE4001S5T2B5 in DeltaV systems?
A8: It provides reliable input signal detection, robust electrical isolation, integrated diagnostics, and seamless compatibility with the DeltaV architecture, ensuring high system integrity and maintainability.
