Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4002S1T2B4 |
| Product Type | Discrete Output Card |
| Manufacturer | Emerson Process Management |
| Series | DeltaV System |
| Function | Provides isolated discrete output channels for process control |
| Number of Channels | 16 isolated digital output channels |
| Output Type | Sourcing discrete (on/off) |
| Output Voltage | 24 VDC nominal |
| Output Current per Channel | 0.5 A maximum |
| Isolation | 250 V RMS channel-to-bus and channel-to-ground |
| Response Time | 5 ms typical |
| Module Power Requirement | 5 V DC (from system backplane) |
| Power Dissipation | 2 W typical |
| System Compatibility | DeltaV and CHARMs systems |
| Status Indicators | Individual LED indicators for output status |
| Built-in Diagnostics | Overcurrent detection and channel fault monitoring |
| Configuration | Configurable via DeltaV Explorer |
| Operating Temperature Range | -40°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting Type | Installed in DeltaV carrier or system baseplate |
| Certifications | CE, UL, CSA, ATEX approved |
| Dimensions | 107 × 41 × 105 mm |
| Weight | 0.6 kg |
FAQ
FAQ
Q1: What is the main function of the VE4002S1T2B4 module?
A1: The VE4002S1T2B4 provides 16 discrete output channels for controlling field devices, such as actuators, relays, and solenoid valves, within DeltaV process automation systems.
Q2: How many output channels does this card support?
A2: It supports 16 independent isolated digital output channels, allowing multiple devices to operate simultaneously under system control.
Q3: What type of output signals does this module deliver?
A3: Each channel delivers a sourcing discrete signal, typically 24 VDC, suitable for driving standard industrial actuators and control devices.
Q4: Are the output channels electrically isolated?
A4: Yes, each output channel is electrically isolated up to 250 V RMS from the system bus and ground, ensuring safety and reducing interference.
Q5: How can I monitor the status of the outputs?
A5: The module features individual LED indicators for each channel, providing real-time visibility of output state and aiding in troubleshooting.
Q6: Does the VE4002S1T2B4 include fault detection?
A6: Yes, built-in diagnostics detect overcurrent and channel faults, which are communicated to the DeltaV system for immediate attention.
Q7: How is the module configured and monitored?
A7: Configuration and monitoring are handled through DeltaV Explorer software, enabling channel mapping, fault management, and real-time monitoring of all output signals.
Q8: What types of devices are commonly connected to this output card?
A8: Typical applications include controlling solenoid valves, relays, motor starters, indicator lights, and other discrete actuators in automated process systems.
