Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4014 |
| Product Name | DeltaV Profibus DP Series 2 Interface Card |
| Function | Interface module for Profibus DP fieldbus integration |
| Bus Type | Profibus DP (Series 2) |
| Installation Type | DIN rail mounted on I/O interface carrier |
| Channel Configuration | 1 Profibus DP channel per card |
| Redundancy | Supports redundant configuration |
| Communication | Integrated with DeltaV system via LocalBus |
| Voltage Supply | 12V DC nominal (from LocalBus) |
| System Compatibility | DeltaV M-series Controllers (MQ, MX, PK) |
| Software Requirement | DeltaV v13.3.1 or higher for Series 2 support |
| Diagnostics | Supports online diagnostics and automatic switchover |
| Environmental Rating | IP20 |
| Operating Temperature | -40 to 70°C |
| Storage Temperature | -40 to 85°C |
| Humidity | 5 to 95%, non-condensing |
| Shock | 10 g, 11 ms half-sine |
| Vibration | 1 mm (5–16 Hz), 0.5 g (16–150 Hz) |
| Conformal Coating | Yes (ISA-S71.04 Class G3 compliant) |
| Dimensions (H x W x D) | 107 x 41 x 105 mm |
| Weight | 0.24 kg |
FAQ
FAQ
Q1: What DeltaV controllers does the VE4014 support?
A1: It supports MQ, MX, and PK controllers and is compatible with M-series I/O hardware.
Q2: Does this card support redundancy?
A2: Yes, VE4014 supports 1:1 redundancy with automatic switchover upon failure of the primary card.
Q3: Is a specific software version required to use this card?
A3: Yes, DeltaV version v13.3.1 or higher is required to support Series 2 Profibus DP cards.
Q4: What communication protocols does the VE4014 support?
A4: It supports the Profibus DP protocol for connecting field instruments and remote I/O.
Q5: Is the card hot-swappable?
A5: Yes, it supports live installation and removal in non-hazardous areas.
Q6: Does this card require external power supply?
A6: No, it draws 12V DC power directly from the DeltaV LocalBus.
Q7: How many Profibus DP channels are supported per card?
A7: Each VE4014 card supports one Profibus DP channel.
Q8: What are the dimensions and weight of the VE4014?
A8: The dimensions are 107 x 41 x 105 mm, and the weight is 0.24 kg.
