Technical Specifications
| Parameter | Description |
|---|---|
| Model | VE4033S2B1 |
| Assembly | KJ3222X1-BA1 + KJ3222X1-EA1 |
| Module Type | Analog Input Module |
| Input Signal | 4–20 mA |
| Channels | 8 channels (typical) |
| Accuracy | ±0.1% typical |
| Isolation | Channel-to-system isolation |
| Response Time | <100 ms |
| Operating Temperature | -20°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5–95% non-condensing |
| Mounting | DeltaV system card slot |
| Power Supply | Backplane powered |
| Dimensions | 107 x 41 x 105 mm |
| Weight | 0.3 kg |
FAQ
FAQ
Q1: Does the module support 4–20 mA input?
A1: Yes, it is designed for standard 4–20 mA analog input signals.
Q2: Are the channels electrically isolated?
A2: Yes, the module provides channel-to-system isolation.
Q3: Can it be used in redundant architectures?
A3: Yes, it is compatible with redundant DeltaV configurations.
Q4: Is hot-swapping supported?
A4: Yes, following DeltaV guidelines.
Q5: Does the module provide loop power?
A5: No, an external loop power supply is required.
Q6: Can it replace other Emerson AI modules?
A6: Replacement depends on hardware and system version compatibility.
Q7: How can the module’s status be monitored?
A7: Status can be viewed through the DeltaV diagnostic interface.
Q8: What applications is it suitable for?
A8: Suitable for analog measurements such as pressure, temperature, level, and flow.
