Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4060C0 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ S-Series Traditional I/O |
| Product Type | High-Density Analog Input Module |
| Application | Process Signal Acquisition for Control Systems |
| Input Channels | 16 Channels |
| Input Signal Type | 4–20 mA Current, ±10 V Voltage |
| Input Resolution | 16-bit |
| Accuracy | ±0.1% of Full Scale (Typical) |
| Input Impedance | 250 Ω (for current input) |
| HART Communication | Supported |
| Isolation | Channel-to-System Isolation |
| Terminal Block Type | 16-Channel AI Mass Termination Block |
| Update Rate | ~100 ms |
| Hot-Swap Capability | Supported |
| Communication Interface | DeltaV LocalBus |
| Power Consumption | < 12 W |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Mounting Type | DeltaV S-Series Carrier Installation |
| Dimensions (L × W × H) | Approximately 263 mm × 58 mm × 28 mm |
| Weight | Approximately 0.45 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson VE4060C0 used for?
The VE4060C0 is used to acquire analog signals from process devices such as transmitters, sensors, and analyzers, feeding data into the DeltaV control system.
Q2: How many input channels does the module have?
It provides 16 analog input channels.
Q3: What types of signals are supported?
The module supports 4–20 mA current and ±10 V voltage signals.
Q4: Does the module support HART communication?
Yes, all channels support HART communication for diagnostics and configuration.
Q5: What are the physical dimensions of VE4060C0?
The module measures approximately 263 mm × 58 mm × 28 mm.
Q6: How much does the module weigh?
The approximate weight is 0.45 kg.
Q7: Can the VE4060C0 be replaced while the system is running?
Yes, it supports hot-swapping, allowing replacement without shutting down the DeltaV system.
Q8: Does VE4060C0 require calibration?
Routine calibration is generally not required, but periodic verification of signal accuracy and wiring integrity is recommended for optimal performance.
