Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE4251 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ M-Series I/O |
| Product Type | 8-Channel Analog Input Module |
| Application | Process Variable Measurement and Monitoring |
| Input Channels | 8 Channels |
| Input Signal Type | 4–20 mA, 1–5 V, 0–10 V (configuration dependent) |
| HART Communication | Supported |
| Resolution | 16-bit |
| Accuracy | ±0.1% of Span (Typical) |
| Input Isolation | Channel-to-System Isolation |
| Input Impedance | 250 Ω (Current Input) |
| Update Rate | 100 ms Typical |
| Communication Interface | DeltaV M-Series Backplane |
| Hot-Swap Capability | Supported |
| Terminal Block Compatibility | DeltaV M-Series Terminal Block |
| Power Consumption | < 8 W |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Mounting Type | M-Series Carrier Installation |
| Dimensions (L × W × H) | Approximately 170 mm × 107 mm × 50 mm |
| Weight | Approximately 0.35 kg |
| Country of Origin | United States |
FAQ
FAQ
Q1: What is the Emerson VE4251 used for?
The VE4251 is used to acquire analog signals from field instruments and transmit process measurements to the DeltaV control system.
Q2: How many channels does the module provide?
The module provides 8 analog input channels.
Q3: Does VE4251 support HART communication?
Yes. The module supports HART-enabled field devices for diagnostics, configuration, and asset management.
Q4: What signal types are supported?
It supports 4–20 mA, 1–5 V, and 0–10 V analog signals, depending on configuration.
Q5: What are the dimensions of VE4251?
The approximate dimensions are 170 mm × 107 mm × 50 mm.
Q6: What is the weight of VE4251?
The module weighs approximately 0.35 kg.
Q7: Can the module be replaced online?
Yes. The VE4251 supports hot-swapping, allowing replacement while the DeltaV system remains operational.
Q8: Does VE4251 require periodic calibration?
Routine calibration is generally not required. However, periodic verification of input accuracy, wiring condition, and HART communication status is recommended.
