Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | VE6018P4 |
| Manufacturer | Emerson |
| Product Series | DeltaV™ M-Series |
| Product Type | Network Interface / Communication Module |
| Application | DeltaV system network communication and controller connectivity |
| Communication Type | Industrial Ethernet |
| Redundancy Support | Yes |
| Hot-Swap Capability | Supported |
| Power Supply | System backplane powered |
| Mounting Type | DeltaV rack / carrier |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% non-condensing |
| Protection Class | IP20 |
| Dimensions (L × W × H) | Approximately 130 mm × 107 mm × 47 mm |
| Weight | Approximately 0.4–0.8 kg |
FAQ
FAQ
Q1: What type of module is VE6018P4?
It is a network interface / communication module, not a field I/O module.
Q2: What is the primary function of VE6018P4?
It enables communication between DeltaV controllers, I/O subsystems, and operator workstations.
Q3: Does VE6018P4 support network redundancy?
Yes, it supports deployment in redundant DeltaV network architectures.
Q4: Can it connect directly to field instruments?
No. Field devices must be connected through dedicated DeltaV I/O modules.
Q5: Where is VE6018P4 installed?
It is installed inside a DeltaV control cabinet or system rack.
Q6: What communication technology does it use?
It uses industrial Ethernet communication within the DeltaV control network.
Q7: What are the dimensions of VE6018P4?
Approximately 130 mm × 107 mm × 47 mm.
Q8: What is the weight of VE6018P4?
Approximately 0.4–0.8 kg, depending on hardware revision and configuration.
