Technical Specifications
| Category | Specification |
|---|---|
| Sensor Type | PR6426 |
| Measuring Range | 24.0 mm (Extended Range) |
| Linearity Error | ≤ 3.5% |
| Sensitivity | 2 V/mm (50.8 mV/mil) |
| Frequency Response | 0 – 20,000 Hz |
| Rise Time | <15 µs |
| Static Range | ±4.0 mm |
| Air Gap (Center) | Approx. 5.5 mm |
| Long-Term Drift | <0.3% |
| Target Material | Ferromagnetic Steel (42CrMo4) |
| Max Surface Speed | 2,500 m/s |
| Min Shaft Diameter | ≥200 mm |
| Operating Temperature | -35 to 175°C (Sensor) -30 to 100°C (Converter) |
| Temperature Excursion | <4 hours at 200°C (Sensor) |
| Max Cable Temperature | 200°C (Sensor) |
| Temperature Error | -0.3%/100K (Zero) <0.15%/10K (Sensitivity) |
| Pressure Resistance | 6,500 hPa (Sensor head) |
| Shock & Vibration | 5g @ 60Hz @ 25°C (Both units) |
| Supply Voltage Range | -23V to -32V (Output -4V to -20V) -21V to -32V (Output -2V to -18V) |
| Connection | Lemo plug (Sensor), Screw terminals (Power/Output) |
| Mounting Method | M5x20 screws (Included) |
| Protection Class | IP20 (Converter) |
| Certifications | CE, ATEX, IECEx, CSA, UL |
| Hazardous Area Approvals | Intrinsically Safe (Ex ia), Non-sparking (Ex nA) |
| Housing Material | Converter: LMgSi 0.5 F22 Sensor: Stainless Steel/PTFE Cable |
| Weight | Converter ~120 g Sensor with 1m cable ~800 g (Total ~0.92 kg) |
| Sensor Diameter | 32 mm |
FAQ
FAQ
Q1: What types of machinery is this product suitable for?
A1: It is suitable for steam turbines, gas turbines, hydro turbines, compressors, pumps, and fans.
Q2: Is the system stable for long-term monitoring?
A2: Yes, the sensor features long-term drift of less than 0.3%, making it ideal for continuous use.
Q3: What is the maximum cable length available?
A3: Typical lengths are 4 m, 5 m, 8 m, and 10 m. Custom lengths may be available upon request.
Q4: Is the product certified for use in hazardous areas?
A4: Yes, it supports ATEX, IECEx, and CSA certifications for both Ex ia and Ex nA types.
Q5: How does the sensor connect to the converter?
A5: The sensor connects via a self-locking Lemo plug to ensure a secure signal path.
Q6: What is the accuracy of the system?
A6: For a 24 mm measurement range, the linearity error is ≤ 3.5%.
Q7: What is the operating temperature range?
A7: The sensor supports -35°C to 175°C; the converter supports -30°C to 100°C.
Q8: Is installation complex?
A8: No, the converter uses standard M5 screws and the sensor comes with a mounting bracket, making installation straightforward.
