Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | PR6423/007-030+CON021 |
| Brand | EPRO |
| Type | Eddy Current Sensor with Signal Converter |
| Measurement Principle | Non-contact eddy current displacement measurement |
| Probe Diameter | 8 mm |
| Measurement Range | 0 to 3.0 mm |
| Sensitivity | 4 mV/μm |
| Frequency Response | 0 to 10 kHz |
| Linearity | ≤ ±1% of full-scale |
| Repeatability | ≤ ±0.5% of full-scale |
| Operating Temperature | -35°C to +180°C (-31°F to +356°F) |
| Storage Temperature | -40°C to +200°C (-40°F to +392°F) |
| Housing Material | Stainless steel |
| Output Signal | Conditioned analog voltage output via CON021 |
| Power Supply | ±15 VDC via CON021 module |
| Compatible Driver | CON021 included |
| Mounting Type | Threaded or clamp mount |
| Vibration Resistance | 20 g, 10–2000 Hz |
| Shock Resistance | 100 g, 11 ms |
| Insulation Resistance | ≥10 MΩ @ 500 VDC |
| Protection Rating | IP67 |
| Sensor Head Diameter | 8 mm |
| Weight | 0.22 kg |
FAQ
FAQ
Q1: What is the main purpose of the Epro PR6423/007-030+CON021 sensor?
A1: It provides precise non-contact measurement of shaft displacement and vibration with a conditioned output suitable for control and monitoring systems.
Q2: What is the measurement range of this sensor?
A2: The sensor measures displacement over a range of 0 to 3.0 mm.
Q3: What is the function of the CON021 module included with this sensor?
A3: The CON021 module converts raw eddy current signals into a conditioned analog voltage output for easy integration into monitoring systems.
Q4: Which materials can this sensor detect effectively?
A4: It is optimized for conductive metallic targets such as steel, iron, and other ferromagnetic materials.
Q5: Can this sensor operate in harsh industrial environments?
A5: Yes, with an IP67 rating, it is protected against dust, oil, and moisture.
Q6: How well does the sensor tolerate vibration and shock?
A6: The sensor is rated for 20 g vibration (10–2000 Hz) and 100 g shock (11 ms), ensuring reliable operation in demanding environments.
Q7: How is measurement accuracy maintained over time?
A7: Accuracy is ensured through stable calibration, temperature compensation, and a robust stainless steel housing.
Q8: In what applications is the PR6423/007-030+CON021 typically used?
A8: It is commonly applied in turbine monitoring, compressors, bearing vibration detection, and predictive maintenance systems in industrial plants.
