Technical Specifications
| Parameter | Specification |
|---|---|
| Sensor Type | Non-contact Eddy Current Sensor |
| Sensor Tip Diameter | 8 mm |
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Scale Factor (ISF) | 8 V/mm (203.2 mV/mil) ±5% (0 to 45°C) |
| Linearity Deviation (DSL) | ±0.025 mm (±1 mil) within 0 to 45°C |
| Minimum Shaft Diameter | 25 mm (0.79 in) |
| Target Material | Ferromagnetic Steel (42CrMo4 / AISI 4140) |
| Protection Class | IP66 (IEC 60529) |
| Operating Temperature | Sensor & 1m Cable: -35 to +180°C Connector/Cable: -35 to +150°C |
| Materials | Tip: PEEK Case: Stainless Steel Cable: PTFE Connector: Nickel-plated Brass |
| Weight | Approx. 0.1 kg (100 grams / 3.53 oz) |
| Sensor Head Diameter | 8 mm |
| Cable Diameter (Standard) | 2.8 mm (Min. bend radius: 25 mm) |
| Cable Diameter (Armored) | 6.0 mm (Min. bend radius: 35 mm) |
| Certifications | CE, ATEX, IEC-Ex, CSA, UL compliant |
| Intrinsic Safety Ratings | T6: ≤64°C / T4: ≤114°C / T3: ≤160°C |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the linear measuring range of the PR6423/011-010 sensor?
A1: The linear measurement range is 2 mm (80 mils).
Q2: What is the minimum target shaft diameter for correct operation?
A2: The minimum shaft diameter is 25 mm (0.79 inches).
Q3: What is the initial recommended air gap?
A3: The initial air gap is 0.5 mm (20 mils).
Q4: What materials are used in the construction of the sensor?
A4: The tip is made of PEEK, the housing is stainless steel, the cable is PTFE, and the connector is nickel-plated brass.
Q5: Is this sensor suitable for hazardous areas?
A5: Yes, it is certified for intrinsic safety according to ATEX, IEC-Ex, and CSA standards.
Q6: What environmental protection rating does the sensor have?
A6: The sensor complies with IP66 protection class under IEC 60529.
Q7: What is the weight of the sensor including 1-meter cable?
A7: The total weight is approximately 0.1 kg (100 grams).
Q8: What is the operating temperature range of this sensor?
A8: The sensor can operate from -35°C to +180°C.
