Technical Specifications
| Parameter | Description |
|---|---|
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Incremental Scale Factor (ISF) | 8 V/mm (203.2 mV/mil), ±5% (0 to 45°C) |
| Deviation from Straight Line | ±0.025 mm (±1 mil) (0 to 45°C) |
| Minimum Shaft Diameter | 25 mm (0.79 in) |
| Target Material | 42CrMo4 (AISI/SAE 4140); others on request |
| Protection Class | IP66 (IEC 60529) |
| Operating Temp. (Sensor) | -35 to +180°C |
| Operating Temp. (Cable/Conn.) | -35 to +150°C |
| Sensor Tip Material | PEEK (Polyether Ether Ketone) |
| Case Material | Stainless Steel |
| Cable Material | PTFE (Polytetrafluoroethylene) |
| Connector Material | Nickel-plated Brass |
| Weight (with 1m cable) | Approx. 0.1 kg (100 g) |
| Sensor Tip Diameter | 8 mm |
| Thread Size | 3/8”-24 UNF |
| Cable Diameter (Standard) | 2.8 mm, Min. Bend Radius 25 mm |
| Cable Diameter (Armored) | 6 mm, Min. Bend Radius 35 mm |
| Connector Type | Lemo male (11.0 mm) or open cable end |
