Technical Specifications
| Item | Specification |
|---|---|
| Model | PR6424/007-110-CN |
| Product Type | Eddy Current Displacement Sensor |
| Measurement Principle | Non-contact eddy current |
| Sensor Head Diameter | 16 mm |
| Measuring Type | Radial shaft displacement and vibration |
| Output Signal | Analog voltage via compatible driver module |
| Sensitivity | 8 mV/µm typical (with matching driver) |
| Measuring Range | 12 mm |
| Linearity | ≤ ±1% of full scale |
| Resolution | < 1 µm |
| Frequency Response | 0–10 kHz |
| Target Material | Conductive metals (steel standard) |
| Temperature Drift | Minimal thermal drift |
| Environmental Protection | Sealed industrial housing |
| Electrical Connection | Connector interface for driver module |
| Shock Resistance | Designed for high-shock industrial environments |
| Vibration Resistance | Suitable for high-speed rotating machinery |
| Housing Material | Stainless steel |
| Installation Method | Threaded mounting |
| Operating Temperature | -35°C to +180°C |
| Storage Temperature | -40°C to +200°C |
| Relative Humidity | 95% max, non-condensing |
| Weight | 0.2 kg |
FAQ
FAQ
Q1: What distinguishes the PR6424/007-110-CN from other eddy current sensors?
A1: It offers an extended measuring range of 12 mm while maintaining high resolution and stability.
Q2: Can it detect very small shaft vibrations?
A2: Yes, with a resolution under 1 µm, it captures subtle vibration signals accurately.
Q3: How does it respond to rapid temperature changes?
A3: The sensor is designed with low thermal drift to maintain consistent measurements.
Q4: What environments is the sensor optimized for?
A4: It is suitable for harsh industrial environments with shock, vibration, and dust exposure.
Q5: How does it handle metallic target variations?
A5: While optimized for steel, it can measure any conductive metal with minor calibration adjustments.
Q6: Can the sensor be used in real-time monitoring systems?
A6: Yes, its fast response and low latency output are ideal for real-time displacement and vibration monitoring.
Q7: Is the sensor compatible with standard Ovation driver modules?
A7: Yes, it requires a compatible driver module to produce a standard analog voltage output.
Q8: How is sensor alignment ensured during installation?
A8: Threaded mounting allows precise positioning and stable alignment with the target shaft.
