Technical Specifications
| Item | Specification |
|---|---|
| Model | PR6424/011-030 |
| Product Type | 16 mm eddy current displacement sensor |
| Measuring Principle | Non-contact eddy current |
| Application | Shaft displacement, vibration, and eccentricity monitoring |
| Recommended Target Material | Ferromagnetic steel |
| Static Measuring Range | ±2.0 mm |
| Dynamic Measuring Range | 0–1000 µm |
| Sensitivity | Approx. 4 V/mm |
| Linearity Error | ≤ ±1.5% |
| Nominal Gap | Approx. 2.7 mm |
| Operating Temperature | –35 °C to +150 °C |
| Output | Works with Proximitor/conditioning unit |
| Mounting | Threaded installation or bracket mounting |
| Housing Material | Stainless steel, oil-resistant and corrosion-resistant |
| Dimensions | Sensor head diameter 16 mm |
| Weight | 0.2 kg |
FAQ
FAQ
Q1: What is PR6424/011-030 used for?
A1: It is used for non-contact monitoring of shaft displacement, vibration, eccentricity and overall rotor condition in turbines, compressors, pumps and similar rotating machinery.
Q2: What kind of output does it provide?
A2: It requires a proximitor or signal conditioner to convert the eddy-current signal into a standard analog output.
Q3: What is the minimum shaft diameter for proper use?
A3: Recommended for shafts with diameter ≥ 80 mm for reliable measurement.
Q4: Is installation complicated?
A4: No — it mounts via standard threaded mount or bracket, making installation straightforward.
Q5: Can it handle harsh environments (high temperature, oil, vibration)?
A5: Yes — stainless steel housing and industrial-grade construction make it resistant to oil, corrosion, vibration and shock.
Q6: Is it suitable for high-speed rotating equipment?
A6: Yes — it is designed for high-speed shafts, suitable for turbines, compressors, and pumps.
Q7: Does it require frequent maintenance?
A7: No — periodic inspection during scheduled maintenance is sufficient.
Q8: What is the typical service life?
A8: With proper installation and maintenance, it can reliably operate for 8–10 years or more.
