Technical Specifications
| Parameter | Description |
|---|---|
| Model | Epro PR6424/109-100 |
| Sensor Type | 16 mm Eddy Current Sensor |
| Probe Diameter | 16 mm |
| Coil Type | Non-contact eddy current coil |
| Measurement Range | Typically 0 … 2.0 mm (depending on extension cable & driver) |
| Linearity Error | < 1% FS |
| Sensitivity | Approx. 7.87 mV/μm (with matching proximitor) |
| Operating Temperature | -35°C to +180°C |
| Storage Temperature | -40°C to +200°C |
| Housing Material | Stainless steel |
| Insulation Level | Industrial anti-oil, anti-vibration |
| Cable Type | Integrated shielded cable |
| Cable Length | 10 m (specific to “109-100”) |
| Dimensions | Sensor head diameter 16 mm |
| Weight | 0.2 kg |
FAQ
FAQ
Q1: Does the PR6424/109-100 require a specific driver unit?
A1: Yes, it must work with compatible drivers such as Epro/VM600 PR6423 to ensure correct sensitivity and linearity.
Q2: Is the sensor cable replaceable?
A2: No, PR6424 series sensors use an integrated non-removable cable.
Q3: Can the sensor operate in high-temperature environments?
A3: Yes, it supports continuous operation up to +180°C.
Q4: Is the sensor suitable for dirty or vibration-intensive environments?
A4: Yes, its stainless-steel housing and industrial design provide strong resistance to oil, shock, and vibration.
Q5: Can the measurement range be adjusted?
A5: The usable range depends on the driver and extension cable; the probe itself is fixed.
Q6: Is it compatible with monitoring systems from other brands?
A6: Usually yes, through the driver’s output signal, but direct replacement requires checking electrical and scale compatibility.
Q7: Is a dedicated mounting sleeve required?
A7: Recommended, as original mounting accessories ensure proper gap and linearity.
Q8: Can it be used for both displacement and vibration measurement?
A8: Yes, it is suitable for displacement, radial vibration, axial movement, and gap monitoring.
