Technical Specifications
| Parameter | Description |
|---|---|
| Sensor Model | Epro PR6426/010-110 |
| Extension/Driver | CON021/916-120 (matched driver + extension cable) |
| Type | 32 mm Eddy Current Displacement/Vibration Sensor |
| Probe Diameter | 32 mm |
| Measurement Principle | Non-contact eddy current |
| Standard Measurement Range | 0 … 4.0 mm (wide-gap and large-shaft measurement) |
| Sensitivity | Approx. 3.94 mV/μm (with matching driver) |
| Linearity | < 1% FS |
| Operating Temperature | -35°C to +180°C |
| Storage Temperature | -40°C to +200°C |
| Housing Material | Stainless steel |
| Cable Design | Integrated shielded cable |
| Cable Length | 10 m sensor cable + 12 m extension cable (variant-specific) |
| Mounting | Threaded mounting, large-diameter sleeve required |
| Environmental Protection | Industrial oil-resistant, vibration-resistant, EMI-resistant |
| Dimensions | Sensor head diameter 32 mm |
| Weight | 0.92 kg |
FAQ
FAQ
Q1: What is the main difference between PR6426/010-110 and the PR6424 series?
A1: The PR6426 series uses a larger 32 mm probe for wider gaps and large shaft applications, while PR6424 is a standard 16 mm model.
Q2: Must it be used together with CON021/916-120?
A2: Yes, the probe must be paired with the matched driver and extension cable to achieve proper sensitivity and calibration.
Q3: Is it suitable for turbines and compressors?
A3: Yes, it is specifically designed for large rotating machinery and wide-gap measurements.
Q4: Can the cable be removed or replaced?
A4: No, the cable is fully integrated and cannot be modified.
Q5: Can it operate in high-temperature environments?
A5: Yes, it supports continuous operation up to +180°C.
Q6: Is the OEM mounting sleeve required?
A6: Recommended, as it ensures correct linearity and gap stability.
Q7: Is it compatible with VM600 or similar monitoring systems?
A7: Yes, provided the driver output matches the monitoring system input specifications.
Q8: Can it measure both displacement and vibration?
A8: Yes, including radial vibration, axial displacement, and gap monitoring.
