Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Foxboro (Schneider Electric / Invensys) |
| Model | FCP270 |
| Product Number | P0917YZ |
| Product Type | Field Control Processor 270 |
| System | Foxboro I/A Series / Foxboro Evo DCS |
| Main Function | Performs regulatory, logic, timing, sequential control, data acquisition, and alarm processing |
| Fieldbus Support | 2 Mbps and 268 Kbps HDLC Fieldbus |
| FBM Support | Up to 32 × 200 Series FBMs; up to 128 × 200 Series FBMs with FEM100; up to 64 × 100 Series FBMs |
| Control Network | 100 Mbps fiber-optic Ethernet |
| Power Supply | 24 VDC typical |
| Power Consumption | 8.5 W maximum per non-fault-tolerant module |
| Memory | 16 MB SDRAM + 32 MB Flash |
| Fault Tolerance | Supported; redundant version uses two FCP270 processor modules |
| Operating Temperature | 0 to +60°C (32 to +140°F) |
| Housing | Rugged die-cast aluminum |
| Dimensions (L × W × H) | Approx. 14.7 × 5.15 × 11.4 cm |
| Approx. Weight | 0.6 kg |
| Origin | USA |
FAQ
FAQ
Q1: What is Foxboro FCP270 P0917YZ?
A: It is a Field Control Processor 270 (FCP270) used in Foxboro I/A Series and Foxboro Evo distributed control systems.
Q2: What is the product type?
A: The product type is Field Control Processor 270.
Q3: What is the main function of P0917YZ?
A: It performs regulatory, logic, timing, sequential control, data acquisition, and alarm detection/notification together with connected Fieldbus Modules (FBMs).
Q4: How many FBMs can the FCP270 support?
A: It supports up to 32 200 Series FBMs directly. With a FEM100, the capacity can reach 128 200 Series FBMs; it can also support up to 64 100 Series FBMs.
Q5: What communication interfaces does the FCP270 use?
A: The FCP270 connects to the Foxboro MESH control network through 100 Mbps fiber-optic Ethernet and supports 2 Mbps or 268 Kbps HDLC Fieldbus communication.
Q6: Does P0917YZ support redundant operation?
A: Yes. The fault-tolerant configuration uses two FCP270 processor modules installed in adjacent slots, providing continued operation if one processor fails.
Q7: What are the dimensions and weight of P0917YZ?
A: The commonly specified dimensions are approximately 14.7 × 5.15 × 11.4 cm (L × W × H), with a module weight of approximately 0.6 kg.
Q8: What should be checked before replacement?
A: Confirm the FCP270 model, P0917YZ part number, firmware/revision, 24 VDC power configuration, fiber-optic network connection, FBM configuration, and redundancy arrangement before replacement.
